- Page 1 USB-100BASE-T1 CONVERTER USER MANUAL September 2018 Manual-Version: 2.0 Hardware-Version: all...
-
Page 2: Table Of Contents
Content GENERAL INFORMATION ................... 3 Functionality and Features of the USB-100BASE-T1 Converter ......3 Warranty and Safety Information ................ 4 Declaration of conformity ..................5 HARDWARE INTERFACES ..................6 Connectors ......................6 2.1.1 Black MQS Connector ................... 6 2.1.2 Universal Serial Bus Connector ..............7 Other Interfaces .................... -
Page 3: General Information
1 GENERAL INFORMATION 1.1 Functionality and Features of the USB-100BASE-T1 Converter Figure 1—1: USB-100BASE-T1 Converter The Technica Engineering USB-100BASE-T1 Converter transmits data frames from the physical layer BroadR-Reach (100BASE-T1) to USB 2.0. Features: • 1 port 100BASE-T1 with Broadcom BroadR-Reach Technology •... -
Page 4: Warranty And Safety Information
LINKS: The User can download the latest firmware and documentation for the USB-100BASE- T1 Converter here: https://technica-engineering.de/produkt/usb-100base-t1-converter/ 1.2 Warranty and Safety Information Before operating the device, read this manual thoroughly and retain it for your reference. The latest documentation for the 100BASE-T1 MediaConverter_BCM can be downloaded here: https://technica-engineering.de/produkt/100base-t1- mediaconverter_bcm/... -
Page 5: Declaration Of Conformity
1.3 Declaration of conformity Figure 1—2: Declaration of conformity USB-100BASE-T1 Converter User Manual... -
Page 6: Hardware Interfaces
2 HARDWARE INTERFACES 2.1 Connectors On the label on top of the device you can see an overview about all HW-Interfaces of the USB-100BASE-T1 Converter. Figure 2—1: Label of USB-100BASE-T1 Converter with pinning information 2.1.1 Black MQS Connector The pinning of the ECU connectors is listed on the label on top of the device as well. (See Figure 2—1). -
Page 7: Universal Serial Bus Connector
Function n.c. 100BASE-T1 port, positive 100BASE-T1 port, negative Table 2—2: Pinning of black MQS connector 2.1.2 Universal Serial Bus Connector There is one USB 2.0 mini B Port for connection to a laptop or PC. 2.2 Other Interfaces 2.2.1 Status LED The USB-100BASE-T1 Converter has one status LED at the frontside of the case for the 100BASE-T1 Port. -
Page 8: Installation
3 INSTALLATION 3.1 Driver Installation A driver is available for following operating Systems: • Linux x64 • Windows x32 • Windows x64 Download-link https://technica-engineering.de/produkt/usb-100base-t1-converter/ Please follow the described steps for installation: 1) Connect your USB-100BASE-T1 Converter device to your computer and browse your driver installation data folder Figure 3—1: Driver Installation Data Folder USB-100BASE-T1 Converter User Manual... - Page 9 2) Run “USB_to BR_converter_driver_installation.exe” as an administrator, then the driver installation wizard will appear. Figure 3—2: Installation as Administrator 3) Click next to continue installing the driver. Figure 3—3: Start installing the driver USB-100BASE-T1 Converter User Manual...
- Page 10 4) At this step the windows drivers are successfully installed. Click Finish to start installing the LibUsbDotNet library. Figure 3—4: Start Installing LibUsbDotNet Library 5) A window will appear and asking for Installation of the LibUsbDotNet library. Click Run to start installing the library. Figure 3—5: Security Warning from Windows USB-100BASE-T1 Converter User Manual...
- Page 11 6) Click next to continue installing the LibUsbDotNet library and accept agreement. Figure 3—6: LibUsbDotNet Setup Wizard and License Agreement 7) Click next until the LibUsbDotNet library is installed Figure 3—7: Installation Information 8) Click Finish to exit Setup and finish installing the LibUsbDotNet library. Figure 3—8: Finish of Installation USB-100BASE-T1 Converter User Manual...
-
Page 12: Device Installation
3.2 Device Installation A libusb-win32 filter installer will appear directly after Installation of the driver. If not, then go to the directory “C:\Program Files (x86)\Technica Engineering\USB to BR Converter” and run install-filter-win.exe. 1) Select “Install a device filter” to install a device filter for the plugged-in device then click next (If your device is not plugged-in, click cancel to exit wizard). - Page 13 3) After successfully installing your device’s filter, click ok then cancel to exit the wizard. Figure 3—11: Exit of Wizard 4) By this time the apllication is installed, if your device is plugged, a system tray application to configure the USB-BR device should appear in windows system tray and taskbar.
-
Page 14: Installation Of Additional Devices
3.3 INSTALLATION OF ADDITIONAL DEVICES If you want to use a further device and you have already installed the drivers, then go to the directory “C:\Program Files (x86)\Technica Engineering\USB to BR Converter” and run install-filter-win.exe. 1) The libusb-win32 filter installer window should appear, select “Install a device filter”... -
Page 15: Configuration
4 CONFIGURATION The USB-100BASE-T1 Converter is configured by using the Configurator window or using directly the system try icon. Figure 4—1: Configurator System Tray Application Every time a device is plugged the System Tray Application will appear in Windows system tray. Every device’s System Tray Application will be linked to a certain device using the device’s serial number, so if you are using multiple devices every device will have its own system- tray configurator tagged with a different serial number. - Page 16 Configuration Options: • The “Master” button can be used to configure the BroadR-Reach port to work in Master mode. • The “Slave” button can be used to configure the BroadR-Reach port to work in Slave mode. • The “Send to System Tray” button can be used to hide the configurator window and send it to the windows system tray.
-
Page 17: Additional Information
5 ADDITIONAL INFORMATION • The maximum cable length for BroadR-Reach segments is limited to 15 meters. USB-100BASE-T1 Converter User Manual... -
Page 18: List Of Figures
6 LIST OF FIGURES Figure 1—1: USB-100BASE-T1 Converter ................3 Figure 1—2: Declaration of conformity ................5 Figure 2—1: Label of USB-100BASE-T1 Converter with pinning information ....6 Figure 3—1: Driver Installation Data Folder ..............8 Figure 3—2: Installation as Administrator ................. 9 Figure 3—3: Start installing the driver ................ -
Page 19: Changelog
7 CHANGELOG Version Chapter Description Date First release Rework of design and update of all information 25.09.2018 USB-100BASE-T1 Converter User Manual... -
Page 20: Contact
8 CONTACT If you have any questions regarding this product, please feel free to contact us: Technica Engineering GmbH Leopoldstr. 236 80807 München Germany Fax: +49-89-34290265 Info@technica-engineering.de www.technica-engineering.de USB-100BASE-T1 Converter User Manual...
