- Page 1 100BASE-T1 MEDIACONVERTER USER MANUAL July 2020 Firmware v3.2.0.0 Manual-Version: 2.4 Hardware-Version: 2.2...
-
Page 2: Table Of Contents
Content GENERAL INFORMATION ..................4 Functionality and Features of the USB 100BASE-T1 MediaConverter ..... 4 1.1.1 Features ......................4 1.1.2 General Information ..................4 1.1.3 LINKS ......................4 1.1.4 General operating and safety strategy of Technica Engineering’s Products 1.1.5 General design rules for the power supply of Technica Engineering’s products ........................ - Page 3 DECLARATION OF CONFORMITY ................21 100BASE-T1 MediaConverter_NXP User Manual...
-
Page 4: General Information
1 GENERAL INFORMATION 1.1 Functionality and Features of the USB 100BASE-T1 MediaConverter Figure 1-1: 100BASE-T1 MediaConverter USB The Technica Engineering USB 100BASE-T1 MediaConverter transmits data frames from the physical layer BroadR-Reach (100BASE-T1) to USB 2.0-LAN. 1.1.1 Features 1 port 100BASE-T1 with Broadcom BroadR-Reach Technology 1 port USB 2.0 mini B... -
Page 5: General Operating And Safety Strategy Of Technica Engineering's Products
Should Technica Engineering’s products be operated in voltage ranges beyond those specified in the norms, which represents a breach of the conditions of operation, then this will void the product warranty and Technica Engineering will assume no liability whatsoever of the results and/or consequences thereof. -
Page 6: Warranty And Safety Information
When integrating the modules in a vehicle or test set-up, the user must ensure appropriate ventilation or air convection. Technica Engineering products must not be considered as a safety element out of context when using safety-critical systems and must be included in the safety assessment when used. The development class in a safety system must be taken into account with standard QM referred to ISO26262. - Page 7 This symbol is only valid in the European Union. If you wish to discard this product, please contact your local authorities or dealer and ask for the correct method of disposal. Technica Engineering GmbH is registered as manufacturer of the brand "Technica Engineering" and...
-
Page 8: Rohs Certificate Of Compliance
1.3 RoHS Certificate of Compliance Figure 1-2 Copy of RoHS Certificate of Compliance 1.4 Scope of Delivery The delivery includes: 1x USB 100BASE-T1 MediaConverter 1x Cableset o Cable for USB 2.0 to Mikro USB plug o Connector for MQS o 100BASE-T1 Cabling o Crimp contacts 100BASE-T1 MediaConverter_NXP User Manual... -
Page 9: Hardware Interfaces
2 HARDWARE INTERFACES 2.1 Connectors On the label on top of the device you can see an overview about all HW-Interfaces of the 100BASE-T1 MediaConverter USB. Figure 2-1: Label of USB-100BASE-T1 Converter with pinning information 2.1.1 Black MQS Connector The pinning of the ECU connectors is listed on the label on top of the device as well. (See 2-1) ABLE... -
Page 10: Universal Serial Bus Connector
2.2 Other Interfaces 2.2.1 Status LED The USB 100BASE-T1 MediaConverter has one status LED at the frontside of the case for the 100BASE-T1 Port. It is lit when there is linkup. It is toggling when there is communication. Note: There is a bug in the used BroadR-Reach PHY. When the 100BASE-T1 Plus and Minus lines are swapped, and the 100BASE-T1 port is set to Slave then the Link LED is lit, but there is no data transmission possible. -
Page 11: Installation
3 INSTALLATION A driver is available for following operating Systems: Linux x64 Windows x32 and x64 Download-link https://technica-engineering.de/en/produkt/usb-100base-t1-converter/ 3.1 Installation for Windows Unzip the downloaded driver pack somewhere. It contains the file USB-BR.exe Double click to the USB-BR.exe-file for execution Click “Next”... - Page 12 In case you have an old application running the installer will prompt to close automatically Click “Install” for completing the installation Click Finish for closing the installation setup 100BASE-T1 MediaConverter_NXP User Manual...
-
Page 13: Installation For Linux
3.2.2 Try Application Installation Navigate \technica-usbbr_linux\linux-technicausbbr-tray-vx.x.x\linux- technicausbbr-tray-master folder to install tray application. This package provides a tray application to manage Technica Engineering USB BroadR-Reach converters. Requirements/Dependencies: cmake (v3.1 or higher) gtk+-3.0 libudev libappindicator 100BASE-T1 MediaConverter_NXP User Manual... - Page 14 Installation: If you are using Ubuntu then execute following command to install dependencies: sudo apt-get install cmake libgtk-3-dev libudev-dev libappindicator3-dev To install, please run: ./install.sh Enter your superuser (sudo) password when asked. After successful installation a tray icon will appear (top right) with Technica application that will allow you to configure the device.
-
Page 15: Configuration
4 CONFIGURATION 4.1 In Windows The USB 100BASE-T1 MediaConverter is configured by using the Configurator window or using directly the system try icon. After successful installation, you will see a new window with a drop-down menu containing a list of all Technica Engineering 100BASE-T1 USB devices connected to your PC. -
Page 16: In Linux
4.2 In Linux After successful installation of drivers, it is already possible to control master/slave mode by using ethtool: For master mode: sudo ethtool -s <interface name> mdix off For slave mode: sudo ethtool -s <interface name> mdix on With Tray Application it is the same as in Windows 100BASE-T1 MediaConverter_NXP User Manual... -
Page 17: Additional Information
5 ADDITIONAL INFORMATION The maximum cable length for BroadR-Reach segments is limited to 15 meters. The single unshielded twisted pair cable (UTP) must fulfill the IEEE 100BASE- T1 specifications 100BASE-T1 MediaConverter_NXP User Manual... -
Page 18: List Of Figures
6 LIST OF FIGURES Figure 1-1: 100BASE-T1 MediaConverter USB ..............4 Figure 1-2 Copy of RoHS Certificate of Compliance ............8 Figure 2-1: Label of USB-100BASE-T1 Converter with pinning information ....9 Figure 4-1: Tray Application ................... 15 100BASE-T1 MediaConverter_NXP User Manual... -
Page 19: Changelog
Added information on General Operating and Safety Strategy July 2020 of Technica Engineering’s Products 1.1.5 Added information on General Design Rules for the Power Supply of Technica Engineering’s Products Warranty and Safety Information updated RoHS Certificate of Compliance added Declaration of conformity added 100BASE-T1 MediaConverter_NXP User Manual... -
Page 20: Contact
8 CONTACT If you have any questions regarding this product, please feel free to contact us: Technica Engineering GmbH Leopoldstr. 236 80807 München Germany Technical support: support@technica-engineering.de General information: Info@technica-engineering.de Most current user manuals and product information: https://technica-engineering.de/ 100BASE-T1 MediaConverter_NXP User Manual... - Page 21 že produkt 100BASE-T1 MediaConverter USB converter-usb/ (TE-1350), souladu směrnicí 2014/30/EU. Úplné znění EU prohlášení o Español shodě je k dispozici na této internetové adrese: Por la presente, Technica Engineering GmbH https://technica- declara producto 100BASE-T1 engineering.de/produkt/100base-t1-media- MediaConverter USB (TE-1350), es conforme converter-usb/ Directiva 2014/30/UE.
- Page 22 EUconformiteitsverklaring worden https://technica- geraadpleegd op het volgende internetadres: engineering.de/produkt/100base-t1-media- https://technica- converter-usb/ engineering.de/produkt/100base-t1-media- converter-usb/ Latviešu Polski Ar šo Technica Engineering GmbH deklarē, ka produkts 100BASE-T1 MediaConverter USB Technica Engineering GmbH niniejszym (TE-1350), atbilst Direktīvai 2014/30/ES. Pilns oświadcza, że produkt 100BASE-T1 ES atbilstības deklarācijas teksts ir pieejams MediaConverter USB (TE-1350), jest zgodny z šādā...
- Page 23 Slovensko Slovensky Technica Engineering GmbH potrjuje, da je Technica Engineering GmbH týmto vyhlasuje, izdelek 100BASE-T1 MediaConverter USB (TE- že produkt 100BASE-T1 MediaConverter USB 1350), skladen z irektivo 2014/30/EU. Celotno (TE-1350), slade smernicou besedilo izjave EU o skladnosti je na voljo na 2014/30/EÚ.
