Technica Engineering MATEnet 100BASE-T1 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

100/1000BASE-T1
MEDIACONVERTER
MATEnet
USER MANUAL
July 2022
Manual-Version: 1.5
Firmware: 1.0.0
Hardware: v2.4 and higher

Advertisement

Table of Contents
loading

Related Manuals for Technica Engineering MATEnet 100BASE-T1

Summary of Contents for Technica Engineering MATEnet 100BASE-T1

  • Page 1 100/1000BASE-T1 MEDIACONVERTER MATEnet USER MANUAL July 2022 Manual-Version: 1.5 Firmware: 1.0.0 Hardware: v2.4 and higher...

  • Page 2: Table Of Contents

    Content Product description ..................4 Functionality ......................4 1.1.1 Features ......................4 1.1.2 General information ..................5 1.1.3 Links ........................ 5 1.1.4 General operating and safety strategy of TE products....... 5 1.1.5 General design rules for the power supply of TE products ......6 Warranty and safety information .................
  • Page 3 Contact ......................22 10 Declaration of conformity ................23 100/1000BASE-T1 Media Converter MATEnetUser Manual...

  • Page 4: Product Description

    Automotive ethernet though similar in functionality has some differences in comparison to standard ethernet. To interact between the two technologies, a converter is needed. The Technica Engineering 100/1000BASE-T1 MediaConverter MATEnet is a physical layer converter providing conversion between100/1000BASE- T1 and 100 BASE-TX or 1000BASE-T with a constant delay of about 2 µs.

  • Page 5: General Information

    Should Technica Engineering’s products be operated in voltage ranges beyond those specified in the norms, which represents a breach of the conditions of operation, then this will void the product warranty and Technica Engineering will assume no liability whatsoever for the results and/or consequences thereof.

  • Page 6: General Design Rules For The Power Supply Of Te Products

    1.1.5 General design rules for the power supply of TE products The power supply solution of Technica Engineering’s products is equipped with a self- protection mechanism. This automatic function protects the internal electronic components against excessive temperature and too high supply voltage by switching the device off.
  • Page 7 When integrating the modules in a vehicle or test set-up, the user must ensure appropriate ventilation or air convection. Technica Engineering products must not be considered as a safety element out of context when using safety-critical systems and must be included in the safety assessment when used. The development class in a safety system must be considered with standard QM referred to as ISO26262.

  • Page 8: Rohs Certificate Of Compliance

    1.3 RoHS certificate of compliance Technica Engineering’s 100/1000BASE-T1 Media Converter MATEnet complies with RoHS (Restriction of Hazardous Substances Directive), see Certificate of Compliance CHAPTER 1.4 Scope of delivery The delivery includes: 1x 100/1000BASE-T1 Media Converter MATEnet Cable-set can be ordered separately:...

  • Page 9: Hardware Interfaces

    2 Hardware interfaces 2.1 Connectors Here you can see an overview of all HW interfaces of the 100/1000BASE-T1 Media Converter on the front side and backside. Figure 2-1: Front side of MediaConverter Figure 2-2: Backside of MediaConverter 2.1.1 RJ-45 connector (1) This is a standard RJ-45 connector to be used with CAT5e STP cable for 100BASE-TX or 1000BASE-T connections.

  • Page 10: Matenet Connector (2)

    2.1.2 MATEnet connector (2) Name Picture Part Number Tyco 1-PORT MATENET HDR ASSY 2302454-9 90DEG Tyco MATENET, FEMALE INSERT MODUL, 2302450-1 BLACK Tyco Nano MQS crimp contact 1-1703930-2 Table 2-1: Parts of Tyco MATEnet Connector You can use the official Tyco tool for these crimp contacts. But we recommend purchasing a ready-to-use cord set.

  • Page 11: Power Mqs Connector (3)

    Pinning: Function Data Line Minus (Negative) Data Line Plus (Positive) Figure 2-3: MATEnet Table 2-2: MATEnet Connector Connector 2.1.3 Power MQS connector (3) Name Picture Part Number TE connectivity 1-1418888-5 6pos MQS .63 header 90deg THR 1-969508-2 TE connectivity MQS BU-GEH 6P Distributor: mouser.de 928999-1 TE connectivity...

  • Page 12: Debug Connector (4)

    2.1.4 Debug connector (4) The debug connector can be used as a serial interface to interact with the device. This interface enables the user to read TX/RX register counters, SQI values of the channels, CRC errors, and other information. It can also be used for bootloader updates of the device.

  • Page 13: Resetting Error Led

    Activity LED 100 or 1000Base-T1 Ethernet data transmission. Table 2-5 LED Description If the GP LED is ON and Host LED is off, this indicates an error state. The 100/1000BASE-T1 Media Converter MATEnet has LEDs integrated into the RJ-45 connector. For RJ45 connection: Left side: Right side:...

  • Page 14: Configuration

    3 Configuration The 100/1000BASE-T1 Media Converter is configured by four DIP switches on the front side of the device. DIP Switch Status Description ON (up) BASE-T1 Port is set to Master OFF (down) BASE-T1 Port is set to Slave ON (up) 1000 BASE-T1 to 1000 BASE-T conversion OFF (down) 100 BASE-T1 to 100 BASE-TX conversion...

  • Page 15: Link Status Output (Ls) (Pin 2)

    3.1.1 Link status output (LS) (PIN 2) The Link Status PIN 2 outputs a weak 3.3 Volts status signal. There is an integrated 5K Ohm pull-up resistor to 3.3 Volts. This PIN is active low. The pull-down transistor can drain up to 100mA. 3.1.2 Force link down (LD) (PIN 3) If you connect PIN 3 and PIN 1 by a shortcut wire link down is forced.
  • Page 16 The frame contains no specific MAC source or destination. All bytes have the same pattern: 0xA5 and 0x5A in alternation. Figure 3-1: Frame by Frame Generator 100/1000BASE-T1 Media Converter MATEnetUser Manual...

  • Page 17: Standard Use Case

    4 Standard use case Here you can see a standard use case of the 100/1000BASE-T1 Media Converter MATEnet. Figure 4-1: Example of a use case Media Converter Device Under Test DIP Switch 1: The Master/Slave setting, is dependent on the DUT. If DUT is Master, MC must be configured as Slave, DIP Switch 1 must be OFF [down], and vice versa DIP Switch 2: 100/1000 speed...

  • Page 18: Used 100/1000Base-T1 Filter

    5 Used 100/1000BASE-T1 filter The following 1000BASE-T1 Filter is used in the 100/1000BASE-T1 Media Converter MATEnet. Figure 5-1: Used Filter in 100/1000BASE-T1 Media Converter 100/1000BASE-T1 Media Converter MATEnetUser Manual...

  • Page 19: Additional Information

    Data loss may occur. 6.1 Disclaimer The “IEEE Compliant mode” is defined by the chip vendor. Technica Engineering cannot be held responsible for the interoperability of this chip and hence the complete product with other devices if the interoperability issues are caused by the “IEEE Compliant mode”.

  • Page 20: List Of Figures

    7 List of figures Figure 1-1: 100/1000BASE-T1 MediaConverter MATEnet ..........4 Figure 2-1: Front side of MediaConverter ................. 9 Figure 2-2: Backside of MediaConverter ................9 Figure 2-3: MATEnet Connector ..................11 Figure 2-2 Example of information from debug connector ........... 12 Figure 3-1: Frame by Frame Generator ................

  • Page 21: Changelog

    8 Changelog Version Chapter Description Date First release July 2020 Declaration of Conformity added July 2020 Updates Sept 2020 Images updated 2.3.1 Resetting Error LED Oct 2020 Declaration of conformity updated March Disclaimer for Marvell IEEE Mode added 2021 Adaptions for Hardware 2.4 July 2022 100/1000BASE-T1 Media Converter MATEnetUser Manual...
  • Page 22 9 Contact If you have any questions regarding this product, please feel free to contact us: Technica Engineering GmbH Leopoldstr. 236 80807 München Germany Technical support: support@technica-engineering.de General information: Info@technica-engineering.de Most current user manuals and product information: https://technica-engineering.de/en/ 100/1000BASE-T1 Media Converter MATEnetUser Manual...
  • Page 23 MediaConverter MATEnet (TE-1402), je v souladu se směrnicí 2015/863/EU and Español 2014/30/EU. Úplné znění EU prohlášení o Por la presente, Technica Engineering GmbH shodě je k dispozici na této internetové declara que el producto 100/1000BASE-T1 adrese: MediaConverter MATEnet (TE-1402), es https://technica-engineering.de/wp-...
  • Page 24 Technica Engineering GmbH niniejszym oświadcza, że produkt 100/1000BASE-T1 Latviešu MediaConverter MATEnet (TE-1402), jest Ar šo Technica Engineering GmbH deklarē, ka zgodny z dyrektywą 2015/863/EU and produkts 100/1000BASE-T1 MediaConverter 2014/30/UE. Pełny tekst deklaracji zgodnośc MATEnet (TE-1402), atbilst Direktīvai I UE jest dostępny pod następującym adre 2015/863/EU and 2014/30/ES.
  • Page 25 EU o skladnosti je na voljo na naslednjem spletnem naslovu: https://technica-engineering.de/wp- content/uploads/2021/03/eu-declaration-of- conformity-te-1402.pdf Slovensky Technica Engineering GmbH týmto vyhlasuje, že produkt 100/1000BASE-T1 MediaConverter MATEnet (TE-1402), je v slade so smernicou 2015/863/EU and 2014/30/EÚ. Úplné EÚ vyhlásenie o zhode je k dispozícii na tejto internetovej adrese: https://technica-engineering.de/wp-...
