100BASE-T1
1000BASE-T1
MEDIACONVERTR
MEDIACONVERTER
BCM
USER MANUAL
November 2018
Manual-Version: 2.0
Hardware-Version: all

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1000Base-T1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Technica Engineering 1000Base-T1

Summary of Contents for Technica Engineering 1000Base-T1

  • Page 1 100BASE-T1 1000BASE-T1 MEDIACONVERTR MEDIACONVERTER USER MANUAL November 2018 Manual-Version: 2.0 Hardware-Version: all...

  • Page 2: Table Of Contents

    CONTENT GENERAL INFORMATION ................... 3 Functionality and Features of the 1000BASE-T1 Media Converter ....3 Warranty and Safety Information ................ 4 Declaration of conformity ..................5 HARDWARE INTERFACES ..................6 Connectors ......................6 2.1.1 nano-MQS Connector ..................6 2.1.2 RJ45 Ethernet connectors ................8 Other Interfaces ....................

  • Page 3: General Information

    Figure 1—1: 1000BASE-T1 MediaConverter The Technica Engineering 1000Base-T1 MediaConverter converts the new Standard 1000Base-T1 to the widely known 1000Base-T and vice versa. Data Transfer is full duplex in both directions. Additional to this it has option to convert 100Base-TX to 100Base-T1 and vice versa.

  • Page 4: Warranty And Safety Information

    IP 2 0 Operating Temperature: -40 to +80 °Celsius LINKS: The User can download the latest firmware and documentation for the 1000BASE-T1 MediaConvert here: https://technica-engineering.de/produkt/100base-t1-mediaconverter_bcm/ 1.2 Warranty and Safety Information Before operating the device, read this manual thoroughly and retain it for your reference.

  • Page 5: Declaration Of Conformity

    1.3 Declaration of conformity Figure 1—3: Declaration of conformity 1000 BASE-T1 MediaConverter User Manual...

  • Page 6: Hardware Interfaces

    2.1 Connectors On the label on top of the device you can see an overview about all HW-Interfaces of the 1000BASE-T1 MediaConverter. Figure 2—1: Label of 1000BASE-T1 MediaConverter with pinning information 2.1.1 nano-MQS Connector The pinning of the ECU connectors is listed on the label on top of the device as well.
  • Page 7 Function Function n.c. n.c. n.c. n.c. n.c. 100/1000 BaseT1 Positive n.c. n.c. n.c. 100/1000 BaseT1 Negative n.c. n.c. n.c. n.c. n.c. Battery +12 Volt Input n.c. n.c. Battery Ground Input Table 2—1: Pinning of black MQS connector The Tyco Electronics (TE) nano Micro Quad Lock System (nano-MQS) is used. Name Picture Part Number...

  • Page 8: Rj45 Ethernet Connectors

    The 1000BASE-T1 MediaConverter has two status LEDs at the frontside of the case for the 1000BASE-T1 Port. Upper LED: Green Color. It is lit if there is a linkup on the 1000BASE-T1 port. Lower LED: Yellow Color. It is toggling if there is communication on the 1000BASE-T1 port...

  • Page 9: Configuration Of The Device

    3 CONFIGURATION OF THE DEVICE The 1000BaseT1 Media converter is configured by 2 DIP Switches on the front of the device. DIP-Switch Status Description ON (up) 100/1000 BASE-T1 Port is set to Master OFF (down) 100/1000 BASE-T1 Port is set to Slave ON (up) The device is set to 1 Gbit Mode.
  • Page 10 4 1000BASE-T1 Filter The following 1000BASE-T1 Filter is used in the 1000BASE-T1 MediaConverter: The Pulse AE5002 is used. Figure 4—1: Used Filter in 1000BASE-T1 MediaConverter 1000 BASE-T1 MediaConverter User Manual...

  • Page 11: Additional Information

    • The delay time is constant 2.0.us. The delay is independent of the Ethernet packet frame size. • The 1000BASE-T1 MediaConverter_ is optimized for automotive use. The maximum cable length for 100/1000BASE-T1 segments is limited to 15 meters. 1000 BASE-T1 MediaConverter User Manual...

  • Page 12: List Of Figures

    6 LIST OF FIGURES Figure 1—1: 1000BASE-T1 MediaConverter ..............3 Figure 1—2: Declaration of conformity ................5 Figure 2—1: Label of 1000 BASE-T1 MediaConverter with pinning information ... 6 1000 BASE-T1 MediaConverter User Manual...

  • Page 13: Contact

    7 CONTACT If you have any questions regarding this product, please feel free to contact us: Technica Engineering GmbH Leopoldstr. 236 80807 München Germany Technical support: support@technica-engineering.de General information: Info@technica-engineering.de Most current user manuals and product information: https://technica-engineering.de/ 1000 BASE-T1 MediaConverter User Manual...
