- Page 1 Installation Operation Care • • Sonnette ® Cellular Roller Shades PowerView Automation ®...
-
Page 2: Table Of Contents
CONTENTS GETTING STARTED Product View ........................ 1 Tools and Fasteners Needed ..................2 INSTALLATION Installation Overview ....................2 STEP 1: Mount the Installation Brackets ..............3 Inside Mount......................4 Outside Mount ......................5 STEP 2: Attach the Rechargeable Battery Mount to the Headrail, If Applicable ..8 STEP 3: Install the Shade.................... -
Page 3: Getting Started
GETTING STARTED Product View 18V Battery Installation Wand Brackets Headrail Bottom Rail Not Shown: Rechargeable Battery Wand, Satellite Battery Pack, Bottom Rail C-Size Satellite Battery Wand, 18V DC Power Supply, End Cap and XL Installation Brackets... -
Page 4: Tools And Fasteners Needed
GETTING STARTED/INSTALLATION Thank you for purchasing Hunter Douglas Sonnette Cellular Roller Shades with PowerView ® ® Automation. With proper installation, operation, and care, your new shades will provide years of beauty and performance. Please thoroughly review this instruction booklet and the enclosed packing list before beginning the installation. -
Page 5: Step 1: Mount The Installation Brackets
INSTALLATION STEP 1: Mount the Installation Brackets Your order will include the correct number of installation brackets for your shade width, as ■ shown in the table below. NOTE: If your shade’s dimensions exceed 84" in width or length, XL brackets will be included. -
Page 6: Inside Mount
INSTALLATION Mount the Installation Brackets — Inside Mount Prepare the Installation Brackets Use pliers or heavy duty scissors to remove the top ■ tabs on the installation brackets. NOTE: Save these tabs once removed. They may be used as shims, if necessary. Bracket Lever Remove Tab Mount the Installation Brackets... -
Page 7: Outside Mount
INSTALLATION Attach the installation brackets using the screws provided. ■ IMPORTANT: Do not overtighten the screws. Check to ensure the bracket lever can be moved easily side to side. If not, loosen the screws in one-eighth turn increments until the lever can be moved easily. IMPORTANT: The front edges of the installation brackets must be level and aligned to each other. - Page 8 INSTALLATION Center the installation brackets or extension brackets on your marks and mark where to ■ drill the screw holes. A minimum 1 ⁄ " flat vertical surface is required for the installation brackets. Extension ➤ brackets require 1 ⁄ ". The top of the installation brackets or extension brackets should be at the desired ➤...
- Page 9 INSTALLATION If using extension brackets, attach an installation bracket ■ Speed Nuts to the underside of each extension bracket using the speed nuts and screws provided. Screws If you have a headrail-mounted rechargeable battery wand, proceed to “STEP 2: Attach the Rechargeable Battery Mount to the Headrail, If Applicable”...
-
Page 10: Step 2: Attach The Rechargeable Battery Mount To The Headrail, If Applicable
INSTALLATION STEP 2: Attach the Rechargeable Battery Mount to the Headrail, If Applicable Install the Rechargeable Battery Clips Insert the rechargeable battery clips into the back channel of the headrail. ■ IMPORTANT: Position the clips so that the rechargeable battery wand will be between installation brackets. -
Page 11: Step 3: Install The Shade
INSTALLATION STEP 3: Install the Shade Lever Headrail Position the shade so ■ that the front faces you. Slide the Headrail Installation Between the Lever Ensure that each lever ■ Bracket and the Bracket. is pushed to the left side of the bracket before installing the shade. -
Page 12: Step 4: Connect The Power Source
INSTALLATION STEP 4: Connect the Power Source NOTE: When power is connected to the motor, a green LED inside the programming button housing will flash to indicate the shade is ready for operation. Refer to the appropriate page based on your order. ■... - Page 13 INSTALLATION If You Have an Optional Satellite Battery Pack... Mount the Satellite Battery Pack Decide where you want to mount the satellite battery pack. A satellite battery pack may ■ be mounted in any orientation. Mark the screw holes for the wall mount bracket. ■...
- Page 14 INSTALLATION If You Have a Headrail-Mounted Rechargeable Battery Wand... Insert the Rechargeable Battery Wand into the Battery Mount NOTE: The rechargeable battery wand ships fully charged, so it is ready to install out of the package. Match the direction of the arrow on the underside of the battery wand with the arrow on ■...
- Page 15 INSTALLATION Mark the screw holes. ■ Drill the screw holes using a ⁄ " drill bit. ■ Attach the battery mount using the screws provided. ■ CAUTION: Only use the screws provided with the battery mount, designed so that the screws will install flush with the mount.
- Page 16 INSTALLATION If You Have an 18V DC Power Supply... Connect the Power Supply Plug the power cable from the shade ■ into the extension cable. Power Cable from Shade Plug the other end of the extension ■ cable into the 18V DC Power Supply. Wire Retainers Plug the 18V DC Power Supply into a ■...
- Page 17 INSTALLATION If You Have an 18V DC Power Supply with Daisy-Chain Connections... The daisy-chain feature allows up to three PowerView shades to be powered by a single ® 18V DC Power Supply. However, each shade can operate independently. The daisy-chain feature is only available with the 18V DC Power Supply option.
-
Page 18: Operation
OPERATION Testing the Shade Use the programming button to test the shade and ensure that the motor and power source are working correctly. Press the programming button to lower the shade. If the shade does not operate, see ■ “Troubleshooting” on page 18. Press the programming button to raise the shade. - Page 19 Scene Controller ® For information regarding operation and programming of the PowerView Scene Controller, ® refer to your PowerView Automation Scene Controller Guide or the online PowerView Step-by-Step Guide at hunterdouglas.com/operating-systems/motorized/powerview- motorization/manuals. PowerView App Operation ® The PowerView Hub is required for PowerView App operation.
-
Page 20: Resetting The Shade (If Necessary)
OPERATION Resetting the Shade (If Necessary) Calibration Reset The calibration reset is used to recalibrate the shade’s travel limits. 1. Press and hold the programming button for approximately 6 seconds. The shade will move slightly. Release the programming button (the light flashes red). 2. - Page 21 OPERATION Problem The shade does not operate using the programming button. Solution Unplug the power cable from the motor, then plug it back in. An LED inside the programming button housing should flash GREEN four times to indicate the motor has power. Check that the batteries in the battery wand, satellite battery pack, or C-size satellite battery wand are correctly inserted and fresh.
- Page 22 OPERATION Problem Rechargeable battery needs recharging. Solution There are two methods for charging the rechargeable battery wand — the dual charging station or the single charger. CAUTION: Rechargeable Battery Wand can only be charged with Hunter Douglas provided charging options — alternative charging devices may result in permanent damage.
- Page 23 OPERATION Problem Rechargeable battery needs recharging (continued) Recharging Via the Single Charger Solution Remove the rechargeable battery wand from the mount, or insert the single charger cable without removing from the shade. Attach the plug adapter to the charger. ■ Plug the charger into a standard AC outlet.
- Page 24 OPERATION Problem The bottom rail does not raise or lower completely, or its location when fully lowered has changed over time. Solution The batteries may be low in the battery wand, satellite battery pack, or C-size satellite battery wand. Replace the batteries. Check that the power source is securely connected to the power cable and the cables are not pinched or caught in the headrail or installation brackets.
- Page 25 OPERATION Problem The power cord isn't accessible for the use with a satellite battery pack or 18V DC Power Supply. Reroute the Power Cord Solution The power cord is located in the front of the shade for an 18V battery wand. The Satellite Battery Pack and the 18V DC Power Supply require the power cord to be rerouted to the back of the shade.
- Page 26 OPERATION Problem The shade limits need to be adjusted — top limit. Adjusting the Top Limit Solution NOTE: Fine adjustment mode timeout is 60 seconds. If there is no action within 60 seconds, fine adjustment mode exits. Move the shade to the current top limit position. See “Basic Operation” on ■...
- Page 27 OPERATION Problem The shade limits need to be adjusted — bottom limit. Solution Adjusting the Bottom Limit NOTE: Fine adjust mode timeout is 60 seconds. If there is no action within 60 seconds, fine adjustment mode exits. Move the shade to the current bottom limit position. See “Basic ■...
- Page 28 OPERATION Problem The shade raises or lowers unevenly, the bottom rail is not level when fully raised, or the fabric winds unevenly, or starts to rub against one end of the headrail. Solution Keep the bottom rail level while raising the shade. Side-to-side movement while raising the shade may cause fabric to skew.
-
Page 29: Care
CARE Removing the Shade Fully raise the shade. ■ Disconnect the power source from the power cable at the back of the shade. ■ Move each lever of the installation brackets to the left to Top View Back ■ release the shade. A flat blade screwdriver can be used to move the lever. - Page 30 CARE Spot-Cleaning CAUTION: Do not use spot clean treatment on Ainsley , Heritage , Highline , Solstice ™ ™ ™ ™ Textura , Thatcher and Elan Metallic fabrics. ™ ™ ® Prepare a solution of warm water and a mild detergent. ■...
-
Page 31: Declarations
Piekstraat 2, 3071 EL Rotterdam, The Netherlands certify and declare under our sole responsibility that the PV13 conforms with the essential requirements of the EMC directive 2004/108/EC and R&TTE directive 1999/5/EC. A copy of the original declaration of conformity may be found at www.hunterdouglas.com/RFcertifications. - Page 32 If you are not thoroughly satisfied, simply contact Hunter Douglas at (888) 501-8364 or visit hunterdouglas.com. In support of this policy of consumer satisfaction, we offer our Lifetime Limited Warranty as described below.
