- Page 1 Installation Operation Care • • Designer Roller and Designer Screen Shades Standard and Cassette Cordless Lifting System...
-
Page 2: Table Of Contents
CONTENTS Getting Started: Product Views ....................1 Tools and Fasteners Needed ................3 Installation Overview ..................3 Installation: Mounting Types and Window Terminology ............4 Mount the Installation Brackets — Inside or Ceiling Mount for Standard Shades ... 4 Mount the Installation Brackets — Outside Mount for Standard Shades ....5 Mount the Installation Brackets —... -
Page 3: Getting Started
GETTING STARTED Standard Cordless Product Views Bracket Standard Cordless Right Side Holder Bracket Mounting Profile Stop Controller Left Side Holder Roller Tube Fabric Bottom Bar End Cap Shade Pull Bottom Bar (Not Attached when Delivered) Magnetic Standard Hold-Down Hold-Down Bracket Bracket (Optional) (Optional) - Page 4 GETTING STARTED Product Views Bracket Cassette Cordless Bracket Stop Controller Cassette Fabric Bottom Bar End Cap Shade Pull Bottom Bar (Not Attached when Delivered) Magnetic Standard Hold-Down Hold-Down Bracket Bracket (Optional) (Optional)
-
Page 5: Tools And Fasteners Needed
GETTING STARTED Thank you for purchasing Hunter Douglas Designer Roller and Designer Sceen Shades. With proper installation, operation, and care, your new shades will provide years of beauty and performance. Please thoroughly review this instruction booklet before beginning the installation. -
Page 6: Installation
INSTALLATION Mounting Types and Window Terminology If the installation brackets are mounted correctly, the rest of the installation process will follow easily. To prepare for this important first step, review the mounting types and basic window terminology illustrated below. Molding Head Jamb Jamb Jamb... -
Page 7: Mount The Installation Brackets - Outside Mount For Standard Shades
INSTALLATION Center the brackets on your marks and mark the screw holes. ■ The minimum depth required for mounting is 1 ∕ ". For fully recessed mounting, the ➤ mounting depth varies with the diameter of the fabric roll when the shade is fully raised. Use a ∕... -
Page 8: Mount The Installation Brackets - Inside Or Ceiling Mount For Cordless Cassette
INSTALLATION Attach the installation brackets using the screws provided. ■ IMPORTANT: The front edges of the installation brackets must be level and aligned to each other. Proceed to “Install the Shade” on page 8. ■ Mount the Installation Brackets — Inside or Ceiling Mount for Cordless Cassette Mark 2"... -
Page 9: Mount The Installation Brackets - Outside Mount For Cordless Cassette
INSTALLATION Mount the Installation Brackets — Outside Mount for Cordless Cassette Center the cassette over the window opening at the desired height. Use a pencil to lightly ■ mark each end of the cassette. Alternatively, measure the width of the cassette and use that width to mark the mounting ➤... -
Page 10: Install The Shade
INSTALLATION Install the Shade Standard Installation The groove on the top of the mounting profile fits into the hooks on the installation brackets. Inside or Ceiling Mount Outside Mount Hook Bracket Bracket Hook Mounting Profile Mounting Profile Install the shade into the installation brackets. ■... -
Page 11: Install The Shade Pull
INSTALLATION Install the Shade Pull The shade pull is not attached when delivered. Detach the screw from the shade pull. Insert the screw through the ■ bottom bar so the screw head is on the back side of the bottom bar. Attach the shade pull with the screw. -
Page 12: Attach The Magnetic Hold-Down Brackets (Optional)
INSTALLATION Attach the Magnetic Hold-Down Brackets (Optional) Lower the shade. ■ Place the magnetic hold-down bracket onto the bottom rail just ■ Bottom Rail inside the end cap, oriented as shown. Hold the bracket while opening and closing the shade slightly ■... -
Page 13: Operation
OPERATION Operate the Shade Lowering the Shade Pull down and release. The shade stops ■ where released. Raising the Shade Pull the shade down about an inch and ■ release. The shade rises and stops. Shade Adjustment Stop Height Adjustment The upper level stop height can be adjusted on shades wider than 24". - Page 14 OPERATION Speed Adjustment If slight changes in the speed are desired: Completely raise the shade. ■ Turn the left side holder counter-clockwise until it stops. ■ Remove the roller from the mounting profile by pulling it out from the right side holder. ■...
-
Page 15: Troubleshooting
OPERATION Troubleshooting Problem Solution The shade does not roll up, Check that the mounting brackets are level. ■ or it rolls too slowly. Roll-up speed can be adjusted. See “Speed ■ Adjustment” on page 12. The shade does not lower. Check that the window is square by measuring the ■... -
Page 16: Care
CARE Removing the Shade (If Necessary) Standard Cordless Shade Fully raise the shade. ■ While holding the shade, push in the white tab on each bracket to release. ■ Cordless with Cassette Shade Insert the tip of a flat head screwdriver into the ■... - Page 19 Notes...
- Page 20 If you are not thoroughly satisfied, simply contact Hunter Douglas at (888) 501-8364 or visit hunterdouglas.com. In support of this policy of consumer satisfaction, we offer our Lifetime Limited Warranty as described below.
