Assembly Instructions:
SMALL PA RTS LIST
1/4-20 X 5/8"
Glide Wrench
Pan Head Machine Screw
(1) #025069
(10) #026064 (Black)
(12) for 48",60" & 72"
Desks
Chair Rail Bracket
(1) #051024P
for 48"60 & 72" Only
Glide
5/16-18 x 1-5/8"
(4) #025068
Rear Unit to
TOOLS REQUIRED F O R ASSEMBLY:
Unit
Bracket
(1) #052463
Before you begin, please make sure all pa r ts and proper quantities are included. Any pa r ts damaged during shipment must be
reported within 15 days of receipt. To report information regarding damages or if you have any questions, please call 1-800-235-
ATTACHING LEGS TO W O R K S U R-
1
FA C E
A: Position legs, attach with
4 of the 1-3/4" silver screws
(do not tighten screws
completely at this point).
See Figure 1.
For 48",60" & 72" desks only...
B: Attach chair rail bracket
with 2 of the 5/8" screws
(Tighten these screws).
(per desk)
1/4-20 X 1-3/4"
Pan Head Machine Screw
(4) #041289 (Silver)
1/4-20 x 2"
Flat Head Machine Screw
(2) #043771
(3) for 48",60" & 72"
Desks
Dual Unit-to-unit
Bracket
(1) 036281
# 2 p h i l l i ps screwdriver
1600 Johnson St. P.O. Box 400 Chippewa Falls, WI 54729 Ph. 1-800-235-1262 Fax. 1-800-335-0473
email spectrum@spectrumfurniture.com
36 - 72 EVOLUTION D
1/4-20 x 1-3/4" Screws
Chair Rail Bracket for
48", 60",& 72" Desks
1/4-20 x 5/8" Screws
Flip Top Section
ESK
FIGURE 1
1/4-20 x 1-3/4" Screws
This end of leg has
a connector inside.
www.spectrumfurniture.com
Page 1 of 2
052519QR1
