Getting to know your monitor
Front view
Back view
4
5
• Depending on the product specifications, the supported resolution and timing may vary.
• Above diagram may vary depending on the model.
• Picture may differ from product supplied for your region.
1
2
3
6
7
8
9
10
13
11
12
1. Light sensor
2. Control buttons
3. Power button
4. Cable management hole
5. AC power input jack
6. HDMI socket
7. DisplayPort socket
8. Mini DisplayPort socket
9. DisplayPort output socket (for
14
Multi-Stream Transport, MST)
10. Headphone jack
11. USB 3.0 port (upstream 1;
connecting to the PC)
12. USB 3.0 port (upstream 2;
connecting to the PC)
13. USB 3.0 ports (downstream;
connecting to USB devices)
14. Kensington lock slot
