Summary of Contents for EIP CS90H
- Page 1 Drawing : - TPC444 Issue : - 3 Date : - 24/11/16 CS90H INDUSTRIAL DEHUMIDIFIER OWNER’S MANUAL www.eipl.co.uk Page 1 of 12 Get In Touch Our Address Call: 0845 6880112 Puravent, Adremit Limited, Unit 5a, Commercial Yard, Settle, North Yorkshire, BD24 9RH...
- Page 2 Date : - 24/11/16 INTRODUCTION Designed for a wide range of applications, the CS90H dehumidifier is a rugged, industrial unit which utilizes an energy-efficient compressor and a compact portable design to provide easy efficient drying. The CS90H has a number of special features: •...
-
Page 3: Specifications
Drawing : - TPC444 Issue : - 3 Date : - 24/11/16 SPECIFICATIONS : CS90H ODEL : 386mm EIGHT : 353mm IDTH : 564mm EPTH : 38 kg EIGHT : 390 M3/hr IRFLOW : 2300V/ 50Hz/ 1 ph OWER UPPLY... -
Page 4: Installation
DRAINAGE: The CS90H has an integral water pump fitted as standard. This condensate pump is capable of discharging the condensate water 4.3m vertical lift away from the unit & 30m horizontal. The water can, therefore, be discharged into a drain some distance away. -
Page 5: Operation
: - 3 Date : - 24/11/16 OPERATION The following procedures should be followed to test the CS90H for correct operation: After unpacking, examine all external features to confirm damage- free shipment. Report all defects and damage at once. Connect the power cable to a grounded 13 Amp electrical outlet. - Page 6 Drawing : - TPC444 Issue : - 3 Date : - 24/11/16 ii. If the air temperature is above 25° C, frost and/or droplets condensed water should cover entire evaporator coil. F. After continuous running time of approximately 55 minutes, the unit will enter “Hot Gas”...
-
Page 7: Routine Service
Drawing : - TPC444 Issue : - 3 Date : - 24/11/16 ROUTINE SERVICE WARNING: ENSURE THAT THE POWER CORD TO THE MACHINE HAS BEEN DISCONNECTED BEFORE CARRYING OUT ROUTINE SERVICE. THE SERVICING AND REPAIR OF THIS UNIT SHOULD ONLY BE CARRIED OUT BY A SUITABLY QUALIFIED PERSON. - Page 8 Drawing : - TPC444 Issue : - 3 Date : - 24/11/16 REPAIRS Should an electrical component fail, consult the Factory Service Center to obtain the proper replacement part. If refrigerant gas is lost from the machine, it will be necessary to use a refrigeration technician to correct the fault.
-
Page 9: Troubleshooting
Drawing : - TPC444 Issue : - 3 Date : - 24/11/16 TROUBLESHOOTING YMPTOM AUSE EMEDY 1. Check the power from Unit inoperative 1. No power to unit power supply panel 1. Replace the fan motor 1. Fan motor burnt out 2. - Page 10 Drawing : - TPC444 Issue : - 3 Date : - 24/11/16 CS90H SPARE PARTS LIST ESCRIPTION UMBER UANTITY UMBER Defrost Timer 1619508 Filter 2013831 Condenser Coil 2059000 Evaporator Coil 2059001 Capillary Tube 3014249 2 x 30” Drain Tubing 3014338...
- Page 11 Drawing : - TPC444 Issue : - 3 Date : - 24/11/16 WARNINGS This appliance can be used by children from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the application in a safe way and understand the hazards involved.
- Page 12 Tel: +01 757 873 6800 Tel: +49 3043 557241 Fax: +44 (0) 1388 662590 Fax: +01 757 873 3632 Fax: +49 3043 557240 www.eipl.co.uk www.ebacusa.com www.eip-ltd.de sales@eipl.co.uk sales@ebacusa.com sales@eip-ltd.de Page 12 of 12 Get In Touch Our Address Call: 0845 6880112...
