- Page 1 True 365nm WARNING! HIGH INTENSITY 365nm UV LIGHT. DO NOT LOOK DIRECTLY INTO SOURCE. AVOID UNPROTECTED EYE AND SKIN EXPOSURE. Information specifically for: DL-BAR10UV365 – Black with UV LEDS This manual contains important information. Please read before operating fixture. V1.0...
- Page 2 If purchase date can not be provided, warranty period will start at manufacture date. It is the sole discretion of Techni-Lux to repair or replace parts or equipment. All shipping will be paid by purchaser. This warranty does not cover lamps, fuses,...
-
Page 3: Table Of Contents
Table of Contents Specifications ..........................4 Unpacking ...........................5 Purpose of Manual........................5 Power ............................6 Mounting .............................6 Basic Reference ..........................6 Basic Setup Wiring Diagrams ....................7 Operating Setting Buttons ......................7 Fixture Menu (LED Display) .......................8 DMX-512 Control .........................9 DMX Data Connection ......................9 Data Terminator ........................9 Adapters for 3 or 5 pin XLR ....................10 DMX Start Address .........................10 DMX Channel Assignments .....................11... -
Page 4: Specifications
Specifications Fixture Overview • True 365nm UV LED • Rugged Heavy Duty Aluminum Housing • Quiet No Fan Operation • Operating modes: DMX, Standalone, Audio • Independent Control of Each LED • 5 Pin XLR DMX Connectors • PowerCON Type Connectors •... -
Page 5: Unpacking
Unpacking Immediately upon receipt, carefully unpack and inspect the fixture to verify that all parts are present and have been received in good condition. If any parts appear damaged from shipping or the shipping carton shows signs of mishandling, notify the shipper immediately. Retain carton and all packing material for inspection. -
Page 6: Power
Power Do not apply power to the fixture until power source is verified. Do not attempt to use this fixture if it appears damaged. For protection against electric shock, fixture must be connected to suitable earth ground. Make sure fixture is disconnected from power mains before any service. -
Page 7: Basic Setup Wiring Diagrams
Basic Setup Wiring Diagrams There are two basic ways to use the fixture. One is in standalone, which does not require the use of any data lines to be connected nor any controller, each fixture would operate independently based solely on the menu setting. The second method, is to use the units in DMX control. -
Page 8: Fixture Menu (Led Display)
Fixture Menu (LED Display) Use the 4 buttons and display panel located on the rear of the fixture to access its settings. Press the Enter button to select a menu option or save and exit after changing an option. DMX Start Address 1 thru 511 Addr 0-511 1 Channel Mode... -
Page 9: Dmx-512 Control
DMX-512 Control Fixtures require a "Start Address" from 1 to 512, setting the first DMX channel containing data for the fixture (see DMX Background). Before addressing fixtures, consult the manual of the system’s DMX controller to select a desirable addressing scheme. Valid Start Addresses range from 1 to 512. -
Page 10: Adapters For 3 Or 5 Pin Xlr
Adapters for 3 or 5 pin XLR Systems using a mix of 3 and 5 pin XLR DMX interfaces can be accommodated by purchasing adapters or building adapter cables. Numbers designating each pin can be found on connectors. Converting between the two XLR types is done pin-to-pin. Shield wire connects to pin 1, then connect pin 2 to pin 2 and pin 3 to pin 3, regardless of either connector’s gender or pin count. -
Page 11: Dmx Channel Assignments
DMX Channel Assignments This fixture features a 1, 2, 3, 18 or 22 channel DMX mode. Select a Channel Mode that provides the desired level of DMX control. 1-CHANNEL-MODE Channel Function Values Dimmer Dimmer 0 - 100% 2-CHANNEL-MODE Channel Function Values Dimmer Dimmer 0 - 100%... - Page 12 18-CHANNEL-MODE Channel Function Values LED 1 LED 1 0 - 100% LED 2 LED 2 0 - 100% LED 3 LED 3 0 - 100% LED 4 LED 4 0 - 100% LED 5 LED 5 0 - 100% LED 6 LED 6 0 - 100% LED 7 LED 7 0 - 100%...
- Page 13 Show8 Show9 Show10 Show11 Show12 Show13 Show14 Show15 Show16 Sound Off,Pattern Speed Slow->Fast Pattern Speed/Sound Sound ON LED 1 LED 1 0 - 100% LED 2 LED 2 0 - 100% LED 3 LED 3 0 - 100% LED 4 LED 4 0 - 100% LED 5 LED 5 0 - 100%...
-
Page 14: Maintenance
Maintenance Make sure fixture is cool and disconnected from power mains before any service. Weekly operating hours and environmental conditions will establish how often the fixtures need cleaning. Fixtures should be cleaned and inspected at least once a month to maintain optimum performance. -
Page 15: Troubleshooting
Troubleshooting Symptom Possible Cause / Solution No Power Check for power on mains Check main fuse and fuse holder Erratic / No response to DMX Check data cables: connection and proper wiring Check Display settings Check Start Address Incorrectly responds to DMX Check Start Address (Diagnostic technique for DMX issues: Set Check for overlapping addresses... - Page 16 10900 Palmbay Drive • Orlando, FL 32824 U.S.A. www.techni-lux.com...
