- Page 1 Information specifically for: DM-VECTORLED712QB V1.0 This manual contains important information. Please read before operating fixture.
-
Page 2: Important Information
It is the owner’s responsibility to provide invoices for proof of purchase, purchase date and dealer or distributor. If purchase date can not be provided, warranty period will start at manufacture date. It is the sole discretion of Techni-Lux to repair or replace parts or equipment. -
Page 3: Table Of Contents
Table of Contents Specifications ..........................4 Fixture Overview ........................4 Physical.............................4 Lamp Source..........................4 Environmental ...........................5 Electrical ...........................5 Control ............................5 Optics............................5 Rigging............................5 Unit Parts.............................6 Unpacking ...........................7 Save Shipping Materials ......................7 Claims ............................7 Returns .............................7 Power............................8 Voltage Selection........................8 LED Engine ..........................8 Mounting .............................9 Control Panel ..........................10 Control Panel Indicators......................10 Control Panel Display......................10 Control Panel Menu ........................11... -
Page 4: Specifications
Specifications Fixture Overview • Extremely small, fast and powerful LED moving beam • 7 Long Life 12w Quad RGBW LEDS • Independent control of each LED • Pan range of movement: 540° • Tilt range of movement: 270° • High resolution 16 Bit Pan/Tilt movement for accurate positioning •... -
Page 5: Environmental
Environmental Environmental Protection Rating IP20 Maximum ambient temperature 105°F (40°C) Maximum exterior surface temperature 176°F (80°C) Minimum distance to flammable surface 3.3ft (1m) Minimum distance to illuminated surface 3.3ft (1m) Electrical Selectable Voltages Auto Switching 110-240v @ 50 or 60Hz Connection IEC (C13) Power Inlet with Fuse Rated Power... -
Page 6: Unit Parts
Unit Parts 1 Head 2 Yoke 3 Base 4 Control Panel 5 Base Bottom 6 Omega Clamp Adapter... -
Page 7: Unpacking
Unpacking Immediately upon receipt, carefully unpack and inspect the fixture to verify that all parts are present and have been received in good condition. If any parts appear damaged from shipping or the shipping carton shows signs of mishandling, retain all packing material for inspection and notify the shipper immediately. -
Page 8: Power
Power Power is connected to the fixture with an IEC power inlet and cord. Before applying power to fixture, verify input voltage matches the power source voltage. Check all power cords to verify they are of proper type and sufficient rating for the equipment attached. For protection against electric shock, fixture must be connected to suitable earth ground. -
Page 9: Mounting
Mounting Always consult a qualified professional when rigging. This fixture may be placed on any flat surface or truss that is capable of safely supporting the weight. When selecting a mounting position, take into consideration access for routine maintenance. This fixture may be mounted in any position provided there is adequate room for movement and ventilation. -
Page 10: Control Panel
Control Panel Use the Control Panel to access the fixture's Menus. Pressing the MENU Key turns the display on and enables the settings mode. Use UP/DOWN to cycle options and change values, ENTER to select or confirm. Settings are stored and recalled on subsequent power cycles. -
Page 11: Control Panel Menu
Control Panel Menu Menu Option Sub Menu Value Description 0-512 DMX512 Start Address >DmxAddr Address >xxx Dmx512 Operating Trigger Mode Auto >WorkMod Sound Number of Control Channels: 13CH >ChanMod 6= Compact, 13= Standard, 37= Extended 37CH Fast LED Dimming Response DimmMOD Smooth >TOOL... -
Page 12: Dmx-512 Start Address
DMX-512 Start Address The Start Address of a fixture is set using the “Address” mode in the Control Panel Menu. Consult the manual of the system’s DMX512 controller to select a desirable addressing scheme before addressing fixtures. Each fixture connected to the DMX-512 data link requires a Start Address to indicate the first DMX channel containing data designated for that fixture, see DMX- 512 Background. -
Page 13: Dmx-512 Channel Assignment
DMX-512 Channel Assignment The VectorLED 712 Quad Beam has 3 different DMX channel modes: Compact 6 Ch Mode, Standard 13 Ch Mode or Extended 37 Ch mode. The 13 channel mode adds high resolution pan and tilt, reset channel and color macros. The 37 channel mode additionally allows the independent control of each of the 7 LEDS. -
Page 14: Channel Functions By Dmx Values
Channel Functions by DMX Values 6 Ch 13 Ch 37 Ch Compact Standard Extended DMX Value Function Shutter/Strobe Effects 0-19 No LED output – “Shutter closed” 20-49 LED output – “Shutter open” 50-64 Strobe 1 (fast-slow) 65-69 Shutter open 70-84 Strobe 2: opening pulse (fast-slow) 85-89 Shutter open... - Page 15 6 Ch 13 Ch 37 Ch Compact Standard Extended DMX Value Function 45-49 LEE 071-Tokyo blue 50-54 LEE 120-Deep Blue 55-59 LEE 079-Just Blue 60-64 LEE 132-Medium Blue 65-69 LEE 200-Double CT Blue continued continued 70-74 LEE 161-Slate Blue 75-79 LEE 201-Full CT blue 80-84 LEE 202-Half CT BLUE...
-
Page 16: Led Position Layout
6 Ch 13 Ch 37 Ch Compact Standard Extended DMX Value Function 0-255 LED 3 Green 0-255 LED 3 Blue 0-255 LED 3 White 0-255 LED 4 Red 0-255 LED 4 Green 0-255 LED 4 Blue 0-255 LED 4 White 0-255 LED 5 Red 0-255... -
Page 17: Dmx-512 Background
DMX-512 Background DMX-512 is a digital data transmission standard developed by the United States Institute for Theater Technology (USITT). It is designed to enable control of lighting equipment, originally dimmers. DMX deals solely with the formatting of data for transmission and does not dictate how the data is created or used. -
Page 18: Data Link Dmx-512
Data Link DMX-512 For data, this fixture uses XLR (Cannon) type connectors and shielded twisted pair cable approved for EIA-422/EIA485 use. Fixtures are connected in Daisy Chain topography with only one data source and no branching. Systems using 3 or 5 pin DMX interfaces can be accommodated by purchasing 3-to-5 pin adapters or building adapter cables. -
Page 19: Maintenance
Maintenance Make sure fixture is cool and disconnected from power mains before any service. Weekly operating hours and environmental conditions will establish how often the fixtures need cleaning. Fixtures should be cleaned and inspected at least once a month to maintain optimum performance. Accumulation of dust and fog residue increases heat build up, can lead to malfunctions, overheating and reduction in maximum light output. -
Page 20: Accessory Items
Accessory Items (sold separately) Order Code Description CLAMP-MEGA/B Clamp-Mega Black - Heavy Duty CLAMP-CBHALF Coupler Half Cheese borough SAFETYCABLE30S Safety Cable Silver 30” SAFETYCABLE30B Safety Cable Black 30” SAFETYCABLE18B Safety Cable Black 18” SAFETYCABLE18S Safety Cable Silver 18” CA-XLR3/1 Pre-made 1’ 3-pin XLR Cable CA-XLR3/5 Pre-made 5’...
