Table 2. RCM3209/RCM3229 Pinout Configurations (continued)
Pin Pin Name
1 /RES
2 PB0
3 PB2
4 PB3
5 PB4
6 PB5
7 PB6
8 PB7
9 PF4
10 PF5
11 PF6
12 PF7
13 PE7
14 PE6
15 PE5
16 PE4
17 PE3
18 PE1
19 PE0
User's Manual
Default Use
Reset output Reset input
Input/Output CLKB
IA0
Input/Output
/SWR
IA1
Input/Output
/SRD
IA2
Input/Output
SA0
IA3
Input/Output
SA1
Input/Output IA4
IA5
Input/Output
/SLAVEATTN
AQD1B
Input/Output
PWM0
AQD1A
Input/Output
PWM1
AQD2B
Input/Output
PWM2
AQD2A
Input/Output
PWM3
I7
Input/Output
/SCS
Input/Output I6
I5
Input/Output
INT1B
I4
Input/Output
INT0B
Input/Output I3
I1
Input/Output
INT1A
I0
Input/Output
INT0A
Alternate Use
Reset output from Reset
Generator
External Address 0
Slave port write
External Address 1
Slave port read
External Address 2
Slave port Address 0
External Address 3
Slave port Address 1
External Address 4
External Address 5
Slave Attention
I/O Strobe 1
Interrupt 1A
I/O Strobe 0
Interrupt 0A
