Sigma-7 Series SERVOPACKs
Alarm Code Alarm Name
A.A12 Abnormal Communication
(1A12h) Transition
A.A20 Parameter Setting Error
(1A20h)
A.A40 System Initialization Error
(1A40h)
A.A41 Communications Device Ini-
(1A41h) tialization Error
A.A42 System Runtime Error
(1A42h)
A.A47 Parameter Loading Error
(1A47h)
A.A48 Read / Write EEPROM Error
(1A48h)
A.A4F PROFINET Fatal Error
(1A4Fh)
A.AA9 Abnormal Control State
(1AA9h)
A.AAB Impermissible Traversing
(1AABh) Block Data
A.AEF Driver Reset Interruption
(1AEFh)
A.EA0 Command-Option IF Servo
(1EA0h) Unit Initial Error
A.EA1 Command-Option IF
(1EA1h) Memory Check Error
A.EA2 Command-Option IF Servo
(1EA2h) Synchronization Error
A.EA3 Command-Option IF Servo
(1EA3h) Data Error
| | PROFINET Communications - SIEP YEUOC7P 02A Revision 0 | en |
Alarm Meaning
Abnormal communication transition
to Link Down or Controller in Stop
mode during Operation Enable state.
The parameter setting is out of
range.
In power up when non volatile
parameter values exceed the current
Motor Max values.
The system initialization at power on
sequence has failed.
The communications initialization at
power on sequence has failed.
Flash load/Store execution failed
The loading of SERVOPACK infor-
mation has failed
Option card resource or configura-
tion problem
Main power is turned off during one
of the following states:
n S4: Operation
n S3: Switched On
n S51: Switching Off: ramp stop
n S52: Switching Off: quick stop
STW1.10 (controlled by PLC) =
FALSE during Enable Operation
state
Impermissible traversing block data
This alarm occurs on every com-
manded Drive Reset.
Communications could not be initial-
ized between the SERVOPACK and
PROFINET Network Module within
10 seconds.
An error occurred in communications
memory between the SERVOPACK
and PROFINET Network Module.
An error occurred in communications
memory between the SERVOPACK
and PROFINET Network Module.
An error occurred in communications
memory between the SERVOPACK
and PROFINET Network Module.
Maintenance
Alarm Displays > List of Alarms
Servomotor Stop- Alarm
ping Method Reset Pos-
sible?
Fault Reaction Yes
Option Code (6085h)
Fault Reaction Yes
Option Code (6085h)
Fault Reaction No
Option Code (6085h)
Fault Reaction No
Option Code (6085h)
Fault Reaction No
Option Code (6085h)
Fault Reaction No
Option Code (6085h)
Fault Reaction No
Option Code (6085h)
Fault Reaction No
Option Code (6085h)
Dynamic Brake Yes
Fault Reaction
Option Code (6085h)
Fault Reaction Yes
Option Code (6085h)
Disables the drive Yes
Gr.1 No
Gr.1 No
Gr.1 Yes
Gr.1 Yes
