REAR – FRONT AND REAR
Light class
MIDO 140 – 1,40 m
MIDO 160 – 1,60 m
MIDO 180 – 1,80 m
MIDO 200 – 2,00 m
MIDO 220 – 2,20 m
INSTRUCTION MANUAL
FLAIL MOWERS
Medium class
GRINO 160 – 1,60 m
GRINO 180 – 1,80 m
GRINO 200 – 2,00 m
GRINO 220 – 2,20 m
VINO 160 – 1,60 m
VINO 180 – 1,80 m
Serial no:
Translation of the original operator's manual
SaMASZ Sp. z o.o.
Poland, 16-060 Zabłudów, ul. Trawiasta 1
– English –
Established – 1984
NIP PL-966-159-29-76
tel. (+48) (85) 664 70 31
fax (+48) (85) 664 70 41
e-mail: samasz@samasz.pl
www.samasz.pl
Heavy class
MAMUT 250 – 2,50 m
MAMUT 280 – 2,80 m
MAMUT 300 – 3,00 m
IN341EN011
2020.01.22
Edition 11
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SaMASZ MIDO 140
Summary of Contents for SaMASZ MIDO 140
- Page 1 REAR – FRONT AND REAR FLAIL MOWERS Light class Medium class Heavy class MIDO 140 – 1,40 m GRINO 160 – 1,60 m MAMUT 250 – 2,50 m MIDO 160 – 1,60 m GRINO 180 – 1,80 m MAMUT 280 – 2,80 m MIDO 180 –...
- Page 2 Keep this manual for future reference. Well-proven design and quality materials ensure high durability and reliability of our products. We congratulate you on the purchase of your new SaMASZ machine and wish you much pleasure and the very best experience resulting from its operation.
-
Page 3: Table Of Contents
Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT Table of contents page 1. DEVICE IDENTIFICATION ...................... 3 2. INTRODUCTION ......................... 3 3. INTENDED USE OF THE MOWER ..................4 3.1. Technical data ........................... 4 3.2. Construction and operation ....................... 5 3.3. - Page 4 Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT 12. WARRANTY CONDITIONS ....................33 12.1. Warranty procedures ......................33 12.2. Record of warranty repairs ....................35...
-
Page 5: Device Identification
Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT 1. DEVICE IDENTIFICATION The mower identification plate is affixed permanently to the body of the mower shown in Fig. 1. Fig. 1. Location of the identification plate Data plate includes: - name and address of the manufacturer, - model year,... -
Page 6: Intended Use Of The Mower
Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT 3. INTENDED USE OF THE MOWER Light class flail mowers MIDO are designed for mulching squares, pitches, laws, pa central reservations, roadsides and parks. Middle class flail mowers GRINO 160/180/200/220, VINO 160/180 heavy duty class MAMUT 250/280/300 are designed for mulching soil fertilisation aiding plants (lupinus, phacelia, sinapis, rapeseed, field pea, rye) before tillage, as well as plant remnants like thick stalks of e.g. -
Page 7: Construction And Operation
Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT Tab. 3. Technical data MAMUT Mower type: MAMUT 250 MAMUT 280 MAMUT 300 Mowing width [m] 2,50 2,80 3,00 Number of blades (flails) [pcs.] Tractor PTO speed [rpm] 1000 Tractor power [KM] from 100... -
Page 8: Equipment And Spare Parts
Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT 13 12 Fig. 2. Overview of the mower 1 – Suspension frame 8 – Plate 2 – PTO shaft 9 – Cleaning plate (re: VINO) 3 – Driving shaft 10 –... -
Page 9: Flail Knives Applicable In Mowers Mido, Grino, Vino, Mamut
MAMUT 250/280/300 1010-1408 1080 7G8N101CE007007TA It is possible to use shafts with similar technical parameters from different manufacturers after consulting SaMASZ. WARNING! The frequency of lubrication of the articulated telescoping shaft should be carefully adhered to. Points shown in should be Fig. - Page 10 Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT WARNING! Before operating make sure whether mounting direction of knives is correct (see Fig. 19). Tab. 5. Types of flail knives MIDO VINO Types of flail knives GRINO MAMUT KNIFE TYPE...
-
Page 11: Safety Warnings And Cautions
Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT 4. SAFETY WARNINGS AND CAUTIONS 4.1. General rules During operation of the mower the Regulation of the Farm Ministry and Food Economy (Rozporządzenie Ministra Rolnictwa i Gospodarki Żywnościowej) from 12-01-1998 dealing with safety and hygiene during the operation of tractors, machinery, tools and equipment used for farming (Dz. - Page 12 Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT Never start the mower if people or animals are in the proximity of the mower. WARNING! Keep the children away from the mower both in operation and standstill. Always comply with safety decals describing hazards, and warning signs placed on the ...
-
Page 13: Qualifications Of Operator
Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT 4.2. Qualifications of operator To provide safe machine operation each person being the machine operator must meet the following requirements: Operator should hold driving license, have ability to drive vehicles safely and know road traffic ... -
Page 14: Placing The Mower Onto A Transport Vehicle
Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT 4.4.1. Placing the mower onto a transport vehicle The carrier and the driver are responsible for safety during the transport of a mower. All equipment and parts must be secured during transport. The following rules should be observed so that transporting the mower on a transport vehicle is safe: the mower can be lifted only in places designated for this purpose and labeled with a hook sign... -
Page 15: Operating Elements
4.7. Residual risk Despite the fact that the manufacturer of the mower, SaMASZ, in order to eliminate danger assumes responsibility for the design and construction of its mowers, some elements of risk are unavoidable during mower operation. - Page 16 Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT 1) The danger of getting caught or pulled in by the machine This danger occurs during changing the positioning of the mower, or working on the mower while the rotating elements are in operation and with the guards removed.
-
Page 17: Residual Risk Evaluation
Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT 4.7.1. Residual risk evaluation When keeping such recommendations as: thorough familiarizing with operator’s manual, no persons remaining on the machine when operating and during drives, no persons remaining within the mower operation range, ... - Page 18 Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT N-52 N-106 N-117 Use protective gloves N-55 WARNING! flail knives! In case of injury caused by Do not get near to a liquid under pressure, call operating mower a doctor immediately N-167 N-168...
- Page 19 Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT N-14 N-15 N-162 N-28 (1000 rpm) / N-29 (540 rpm) N-05 N-14, N-15, N-162 N-28 N-01, N-03, N-04, N-07, N-09, N-106, N-117, N-167, N-168, N-210, N-52 Fig. 8. Warning decals placed on the mower...
-
Page 20: Operation Of The Mower
Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT 5. OPERATION OF THE MOWER 5.1. Connecting the mower to the tractor The mower should be connected to the tractor using the three point hitch as illustrated in Fig. -
Page 21: Connecting The Pto Shaft
540 rpm. When operating with mower mounted on the front 3-point linkage adjust the machine to PTO speed of 1000 rpm. Follow the procedure: in MIDO 140 flail mower, switch belt pulleys around – at the top SPB 170-3 belt pulley, at the bottom SPB 236-3 belt pulley, in MIDO 160/180/200/220 flail mowers, switch belt pulleys around –... -
Page 22: Preparing The Mower For Transport
Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT holding chains to a permanent part of the body of the tractor and the loop on the guard of the splined shaft of the mower drive shaft. WARNING! If need be, shorten the PTO haft according to its operator’s manual given by the shaft’s manufacturer (Fig. -
Page 23: Preparing The Mower For Operation
Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT road traffic safety and current laws require that during transport over public roads the mower must be equipped with a portable reflective triangle mounted on the back of the mower; while manoeuvring pay special attention to the space around the tractor-mower unit ... -
Page 24: Removing Clogging And Jams
Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT In real life the user should use so called "common sense". In regards with this during intense usage the cost of necessary service checks should be taken into account – see 12. WARRANTY CONDITIONS. -
Page 25: Mounting And Settings
Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT 6. MOUNTING AND SETTINGS 6.1. Setting the mowing height in MIDO, GRINO, MAMUT flail mowers Please adjust the mowing height according to own needs and in accordance with Fig. 15 and Tab. -
Page 26: Maintenance
Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT Tab. 8. Possible mowing heights Mowing heights – A Position in VINO mowers: I + 0 II + 0 III + 0 IV + 0 V + 1 VI + 1 VII + 1 VIII + 1... -
Page 27: Checking The Flail Blades
In the case of excessive vibrations of the machine, please balance the flail shaft. After flail knives are replaced, make sure they are installed in a correct position, as in Fig. 19. Knives can be obtained from the manufacturer of the mower – "SaMASZ". Spinning... -
Page 28: Everyday Maintenance
If necessary replaced bearings and seals (execution of the activity by experts from SaMASZ company), protect working parts (pins, joints, cylinder rods, etc.) against corrosion by applying a thin film ... -
Page 29: Lubrication
Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT Tab. 9. Values of bolt tightness 7. LUBRICATION 7.1. Angle gear Everyday before starting work the oil level should be checked and if necessary refilled by removing plug (1) in the upper part of the gear (Fig. 20). The oil level is checked by removing the control plug (2) on the side of the gear. -
Page 30: Risks Present When Lubricating
Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT Copying shaft should also be greased with (LT – 43) on both sides in points shown in Fig. 22. Lubrication points Fig. 22. Lubrication points of the bearings of copying shaft 7.3. -
Page 31: Defining The Total Weight, Axis Load, Tyre Load Capacity And Minimum Load
Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT 8. DEFINING THE TOTAL WEIGHT, AXIS LOAD, TYRE LOAD CAPACITY AND MINIMUM LOAD ATTENTION ! Admissible total weight of the tractor – machine assembly cannot exceed: − 14 t (tractors first registered before March 31, 2011), −... - Page 32 Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT Calculating minimum weight of front balast M – machine mounted at tractor's rear: P min. Calculating real axis load at tractor's front axis T P rzecz . *If the value of front axis load (T ) is less than 20 % of tractor’s overall weight (T), apply additional load on the P rzecz...
-
Page 33: Malfunctions And Their Correction
Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT 9. MALFUNCTIONS AND THEIR CORRECTION Malfunction Cause Recommendations Adjust belt tautness using the bolt according to the instructions Worn-out belts - replace belts or apply belt Sliding of the belts paste Blocked cutting chamber, remove all foreign material... -
Page 34: Mower Repair And Disposal
Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT 10. MOWER REPAIR AND DISPOSAL WARNING! Before performing any repairs the mower must be disconnected from the tractor. 10.1. Repair Before repairing or assessing whether the mower is still serviceable, the machine should be carefully cleaned of dirt, mud and plant remains. -
Page 35: Warranty Card
Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT 11. WARRANTY CARD REAR – FRONT AND REAR FLAIL MOWER: Serial number Manufacture date Guarantor seal Controller signature Sale date Seller seal Seller signature This product has been checked and deemed fully serviceable and cleared for use. WARNING! The warranty card missing required seals or signatures or which has been corrected or is illegible is void. - Page 36 The manufacturer reserves the right to introduce changes in construction. WARNING! The SaMASZ Company is continually working on improvement and development of all types and models of mowers. For this reason the form, accessories and technology of delivered products can change. No claims can be made based on the data, illustrations or descriptions contained in this manual or the spare parts catalogue.
- Page 37 Rear - front and rear flail mowers Instruction manual MIDO, GRINO, VINO, MAMUT 12.2. Record of warranty repairs Repairs performed and replaced parts Date, seal and signature of person performing the repair. Date, seal and signature of person performing the repair. Date, seal and signature of person performing the repair.
