- Page 1 CENTRALE DI COMANDO pag. 3 MANUALE D’INSTALLAZIONE ED USO CONTROL UNIT pag. 17 INSTALLATION AND OPERATION MANUAL CSB Xtreme (1.2)
-
Page 2: Table Of Contents
Contents 1. INTRODUCTION 2. MAIN CHARACTERISTICS 3. TECHNICAL SPECIFICATIONS 4. INSTALLATION SAFETY 5. PRELIMINARY OPERATIONS 6. INPUT AND OUTPUT FUNCTIONALITY AND CONNECTIONS 6.1 J1 CONTROL UNIT POWER SUPPLY 6.2 J4 FLASHING LIGHT OUTPUT 6.3 J5 OUTPUTS/ACCESSORIES POWER SUPPLY 6.4 J6 ENCODER/INPUTS 6.5 J7 INPUTS/ANTENNA 6.6 J8 BOOM LIGHTS CONNECTOR 6.7 J10... -
Page 3: Introduction
Control unit 1. INTRODUCTION The control unit has been developed to control automatic single-phase barriers with inverter-driven three-phase motor. = Electrical connections confi gured at the factory. 2. MAIN CHARACTERISTICS - Microprocessor logic - 3-digit display for programming and system status - LEDs displaying inputs/outputs status - Up to 4 confi gurable outputs - Integrated radio receiver 433.92MHz, 2 channels, 2 048 codes... -
Page 4: Technical Specifications
Control unit 3. TECHNICAL SPECIFICATIONS - Power supply:............230Vac ±10%, 50/60Hz (115Vac on request) - Flashing light output:....................230Vac; 40W max - Accessory output:...................24Vac; 24W - 1A max 4. INSTALLATION SAFETY In order to reach the level of safety required by current regulations, follow these prescriptions carefully. 1) Make all the connections in the terminal block after carefully reading the instructions given in this manual and observing the general rules and technical standards concerning electrical systems installations. -
Page 5: J6 Encoder/Inputs
Control unit ENCODER/INPUTS ENCODER Supplied already wired. Encoder can trigger in the closing movement only, when the boom hits an obstacle. Select the desired behaviour by programming the parameter - level 1. +V terminal can be used for powering additional sensors (16Vdc not stabilized-100mA max) FRAC N.C. -
Page 6: J8 Boom Lights Connector
Control unit BOOM LIGHTS CONNECTOR EXPANSION CONNECTOR TCP/IP SC RS485 RADIO PROGRAMMER CONNECTOR 7. INVERTER CONNECTIONS 7.1 INVERTER INVERTER SIGNALS FLB FLC CC VI P5 FM OUT NO CC S1 S2 P24 INVERTER CC: Brown POWER SUPPLY F: Yellow R: White CONTROL UNIT 230Vac 50/60Hz with internal protection and fuse. -
Page 7: Programming
Control unit 8. PROGRAMMING 8.1 BASIC FUNCTIONS To access programming, press button F for 2 seconds. Programming is divided into 4 levels. To go to the next level keep key F pressed and press the + key (Sequence 1-2-3-1..). After selecting the level wanted, press push button F to display the functions available in consecutive order. Each time F is pressed it corresponds to a function (... -
Page 8: 1St Level Programming
Control unit LEVEL PROGRAMMING The following table gives the 1st level functions and the single settable parameters. = DEFAULT value set in factory. = parameter value set during installation: must be indicated if DEFAULT value is modifi ed. Function Settable data : Hold-to-run Selects the functio- ... -
Page 9: 2Nd Level Programming
Control unit Connect the N.O. contact of the detector or photocell to the Close contact terminals. If the vehicle is on the detector or in front of the photocell it does not cause immediate closing but rather you have to wait for the signal to be released. -
Page 10: 3Rd Level Programming
Control unit Function Settable data : disabled : enabled, opens automatically during mains failure : enabled, closes automatically during mains failure ATTENTION:THIS SELECTION MAY BE DANGEROUS Exit programming and view machine Status (see notes automation Status Exiting the menu/saving display after the 1st level table) Description of level 2 parameters... -
Page 11: 4Th Level Programming
Control unit - (MAXIMA ULTRA 68, ATM 90°, ATM 180°) Closing speed (%) - (MAXIMA ULTRA 35, Carbon) : Disabled Speed selection input : Enabled : swinging boom not mounted or disabled ... -
Page 12: Radio Receiver
Control unit 9. RADIO RECEIVER 9.1 RECEIVER TECHNICAL SPECIFICATIONS - Max. n° of radio transmitters that can be memorized: 2 048 - Frequency: 433.92MHz - Code by means of: Rolling-code algorithm - N° of combinations: 4 billion 9.2 RADIO CHANNEL FUNCTIONALITY Channel 1: Start command Channel 2:... - Page 13 - 28 -...
-
Page 14: Controlled Entry And Automatic Exit
Control unit 11. CONTROLLED ENTRY AND AUTOMATIC EXIT This solution is recommended when you want to enter a reserved area in both directions. To enter, transit is allowed by means of a reco- gnition command while exiting is automatic. ENTRY The recognition system enables bar- rier opening. -
Page 15: Troubleshooting Guide
Control unit 12. TROUBLESHOOTING GUIDE - In the case of a malfunction, check that the correct barrier was selected (paragraph 5) - Dual fl ashing of the cover lights. Indicates that scheduled maintenance is required. Check the parameters -2ND level, -2ND level, -2ND level. - Page 16 REGISTRO DI MANUTENZIONE MAINTENANCE LOG Dati impianto • Plant data Installatore Installer Cliente Customer Matricola Serial number Data installazione Installation date Data attivazione Activation date Data • Date Descrizione intervento • Intervention description Firme • Signatures Tecnico • Technician Cliente • Customer Tecnico •...
