- Page 1 按供应商要求封面做了出血3mm Yealink Network Technology CO., LTD Yealink VC800 Full HD Video Conferencing System Quick Start Guide Applies to firmware version 63.32.0.3 or later V32.35...
-
Page 3: Package Contents
Conference Phone Expansion Mic×2 B Package We recommend that you use the accessories provided or approved by Yealink. The use of unapproved third-party accessories may result in reduced performance. VC800 system can work with A package or B package. Put the magnet rings on the HDMI cable to prevent electromagnetic interference. - Page 4 Put on a Flat Surface You can put the system on a conference room table, and make sure that the slope is not more than 15 degrees so that the system can operate correctly. Mount on top of a TV The system may fall down when the thickness of the TV is more than 100 mm.
- Page 5 Open the baffle. Steps： Push the bracket along the track of the system. Stick a Velcro onto the bracket. Remove one Velcro. Put the bracket on the top of the TV. Stick a Velcro onto the back of the TV, and make sure that the bracket and the back of the TV are tightly positioned against each other.
- Page 6 Screw specification: M3×8 Punch holes into the wall and then insert the expansion bolts. Steps： Secure the bracket using the T4×30 screws. Push the system along the track of the bracket. Secure the system onto the bracket using the M3×8 screws. Mount on a Ceiling If you choose the ceiling-mounted installation, you need to purchase a bracket separately.
-
Page 7: Remote Control And Cable Ties Installation
Screw specification: M3×8 Screw specification: 1/4”-20 UNC Push the VESA accessory along the track of the system. Steps： Secure the VESA accessory to the system using the M3×8 screws. Align the location pillar at the location hole, and then secure the bracket to the VESA accessory using the 1/4”-20 UNC screw. Mount onto a TV Stand or a Tripod You need to purchase a TV stand or a tripod separately. - Page 8 The system should be used with Yealink original power adapter (48V/0.7A) only. The use of the third-party power adapter may cause the damage to the system. The cable should be replaced at once if its skin is broken.
-
Page 9: Network Environment
VC Hub/Phone port on VC800 codec Wireless Sharing WF50 Wi-Fi USB Dongle WPP20 Wireless Presentation Pod For more information on WPP20 wireless presentation pod, refer to Yealink WPP20 Wireless Presentation Pod Quick Start Guide. Network Environment Bandwidth Requirements Video Resolution... - Page 10 Traditional Deployment If you deploy the system in the head office, make sure it is reachable from public network. If you deploy the system in the branch office, use intelligent traversal to deploy it or just follow the same steps as for the head office. Head Office If you deploy the system in the head office, at least one static public IP address is required to allow branch offices to connect.
-
Page 11: Troubleshooting
Intranet, you have configured port mapping on the firewall or gateway, but find that local system appears black screen and you cannot hear sound when you call Yealink Demo or other systems. The most likely reason is that the firewall or gateway in your environment does not support the ALG feature. - Page 12 As one of the best providers in more than 140 countries and regions including the US, the UK and Australia, Yealink ranks No.1 in the global market share of SIP phones shipments.
