Front and Back Panel Components
Front and Back Panel Components
The following sections describe the front and back panel components for both the
DECserver 716 and DECserver 732.
Front Panel Components
Table 1-1 describes the front panel components, and LEDs, that are illustrated in
Figure 1-1. For problem-solving information using the LEDs, refer to Appendix A,
Problem Solving.
Figure 1-1: Front Panel LEDs and Connectors
DECserver 716
2
1
1
2
3
DECserver 732
2
1
Table 1-1: Front Panel LEDs and Connector Descriptions
Item
Name
1
Reset Switch
2
System OK LED
3
Flash RAM Slot
1-4 Product Description
4
6
8
10
12
14
16
3
5
7
9
11
13
15
4
4
6
8
10
12
14
16
18
3
5
7
9
11
13
15
17
Description
On power up: press this switch until the System OK LED
blinks. This reloads the factory set parameters and all
customized parameters are lost. During Flash load,
pressing and holding the system reset switch will abort the
Flash RAM load and force a network boot.
Lights when the DECserver has power.
On: DECserver has power.
Off: DECserver does not have power.
Provides an opening to insert the optional Flash RAM
Card.
5
6
5
20
22
24
26
28
30
32
19
21
23
25
27
29
31
6
7
11
12
LNK
8
9
10
12
7
11
LNK
8
9
10
3505-03
