Introduction
This control system connects to a display module and pressure senders to allow monitoring and
control of all four corners and optional monitoring of the tank pressure. Each bag can be
manually raised or lowered as well as control of the front two together, rear two together, or all
four together. The bag senders can be either 150 psi units or 400 psi units for high pressure
systems. The tank sender is always the 400 psi unit.
This control system can also be connected to a remote transmitter system to allow individual
remote control of the air bag system. The functions include individual corner up/down, all
up/down, front up/down, and rear up/down.
IMPORTANT: Make sure to always disconnect the negative cable from the battery if you are
going to be working on or under the vehicle. Failure to do so can result in serious injury if the
system is accidentally activated.
Wiring
Main connector
RED
BLACK
YELLOW
BLUE
WHITE/GREEN
GREEN
WHITE/PURPLE
PURPLE
WHTE/ORANGE
ORANGE
WHITE/BROWN
BROWN
Sender connector
GREEN
PURPLE
ORANGE
BROWN
GRAY
BLACK
Display connector
Mates to display
Remote receiver connector
Mates to ARR-2000 module harness connector
ODYR-24-1 and SLX-24-1
Air Bag Display and Control System
constant 12V power
ground
12V accessory power
night dimming (connect to tail light or head light circuit)
right rear down solenoid (not used for FRONT/REAR setup)
right rear up solenoid (not used for FRONT/REAR setup)
left rear down solenoid
left rear up solenoid
right front down solenoid (not used for FRONT/REAR setup)
right front up solenoid (not used for FRONT/REAR setup)
left front down solenoid
left front up solenoid
right rear pressure sender (not used for FRONT/REAR setup)
left rear pressure sender
right front pressure sender (not used for FRONT/REAR setup)
left front pressure sender (front sender for FRONT/REAR setup)
tank pressure sender
ground to senders
(rear sender for FRONT/REAR setup)
1
MAN# 650052
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Dakota Digital ODYR-24-1
Summary of Contents for Dakota Digital ODYR-24-1
- Page 1 ODYR-24-1 and SLX-24-1 Air Bag Display and Control System Introduction This control system connects to a display module and pressure senders to allow monitoring and control of all four corners and optional monitoring of the tank pressure. Each bag can be manually raised or lowered as well as control of the front two together, rear two together, or all four together.
- Page 2 The gauge needs only the RED and BLACK wires connected to light up. When the BLUE wire has 12 volts, it will dim the display for night viewing. The senders must be Dakota Digital part SEN-03-1 or SEN-03-5. Sending units from other manufacturers will cause incorrect readings.
- Page 3 Setting the sender type: While the tank sender is always a 400 psi type, the bags will work with either 150 psi senders or 400 psi senders. The procedure for setting the sender type is as follows: 1. Push and hold in the joystick while you turn the key on. The display should light up and show “SETUP”.
- Page 4 Using the auto raise feature: This unit can optionally be set to adjust the bag pressures to a preset level every time the key is turned on. This feature can also be turned off. The auto raise will quit if the joystick is moved in any direction, the tank pressure drops to the same level as one of the bags, or 20 seconds has expired.
- Page 5 SENDER WIRING GRAY connect to tank pressure sender (optional). The GRAY wire should be left open if the tank pressure is not being monitored. Sender Wiring for 4 bag systems: GREEN connect to the right rear pressure sender. PURPLE connect to the left rear pressure sender. ORANGE connect to the right front pressure sender.
-
Page 6: Troubleshooting Guide
Troubleshooting guide. IMPORTANT: Make sure to always disconnect the negative cable from the battery if you are going to be working on or under the vehicle. Failure to do so can result in serious injury if the system is accidentally activated. Problem Possible cause Solution... - Page 7 OPERATION AS REMOTE CONTROL SYSTEM The remote system is active when the large red power wire has power and the accessory power wire does not. This prevents accidental operation using the remote system while the vehicle is being driven. When the remote system is ready and waiting to operate the red light on the controller will be flashing slowly.
- Page 8 Front up Front down All down All up/auto raise Rear up Rear down OPERATION FOR MODE 2 The key chain transmitter has six buttons. They are labeled I, II, III, IV, V, and VI. Button I raises the front two bags together. Button II lowers the front two bags together.
-
Page 9: Transmitter Programming
TRANSMITTER PROGRAMMING All of the transmitters to be programmed into the system should be available. This sequence will erase any previously programmed transmitters. If a transmitter is lost or stolen, go through the programming sequence with the remaining transmitters and the lost one will be erased. 1. -
Page 10: Service And Repair
Any action for breach of any warranty hereunder, including any implied warranty of merchantability, must be brought within a period of 24 months from date of original purchase. No person or representative is authorized to assume, for Dakota Digital, any liability other than expressed herein in connection with the sale of this product.
