kingsley-bate CO-18 Assembly Instructions

ASSEMBLY INSTRUCTIONS FOR THE CO-18
RIGHT END FRAME
clean, flat, soft surface to avoid marring the wood.
NOTE: During assembly of the furniture please match all joints with the corresponding
letters or numbers stamped on the furniture.

STEP-II

Fit the BACK, SEAT and BOTTOM STRETCHER tenons into the END
FRAME mortise holes using the stamped numbers or letters as guides. If
necessary, gently rock the BACK, SEAT and BOTTOM STRETCHER
while pushing the tenons into the mortise holes until all joints fit snugly
together.
assembly as shown in the photographs. All dowels and dowel holes are properly marked with
stickers. NOTE: DO NOT FORCE THE DOWELS; ANY EXCESS CAN EASILY BE
SANDED AWAY. IF THE DOWELS ARE NOT FLUSH DO NOT CONTINUE TO
DRIVE THE DOWELS, YOU MIGHT DAMAGE THE ITEM.
KINGSLEY~BATE
Fine Garden Furniture
BACK SEAT
* NOTE:
A TENON
B MORTISE HOLE

STEP-I

Unpack, inspect and
lay the parts on a

STEP-III

Fit the remaining END FRAME mortise
holes over and onto all exposed tenons
and using a rubber mallet gently tap the
END FRAME evenly until all joints fit
snugly together. Carefully
dowels into the pre-drilled holes of the
LEFT END FRAME
hammer
