  • Page 1 Spray Height Controller Hardi OEM End-User Installation Manual Improving the competitiveness of Industry and Agriculture through Precision Measurement...
  • Page 2 NOTICE NORAC Systems International Inc. reserves the right to improve products and their specifications without notice and without the requirement to update products sold previously. Every effort has been made to ensure the accuracy of the information contained in this manual. The technical information in...
  • Page 3 INTRODUCTION Congratulations on your purchase of the NORAC UC4+ Spray Height Controller. This system is manufactured with top quality components and is engineered using the latest technology to provide operating features and reliability unmatched for years to come. When properly used the system can provide protection from sprayer boom damage, improve sprayer efficiency, and ensure chemicals are applied correctly.
  • Page 4 INSTALLATION 1. Install the UC4+ Control Panel (E01) in the cab of the sprayer. Mount the panel where it will be clearly visible and within easy reach of the operator. A good spot to mount the UC4+ control panel is on the right hand side of the cab to the Roll Over Protection Bar (ROP).
  • Page 5 Figure 2 – Cable Configurations: C10 and C11 2. Connect the power cable (C10) to the UC4+ Control Panel in the sprayer cab. Ensure that both plugs (P16A and P4) are connected to the panel (Figure 2). Ensure that the UC4+ Control Panel is OFF for the remaining installation (Bottom of switch pressed IN).
