Pull out Desk - Star
7607729
- Please keep for future reference

Dimensions

Length - 60cm
Depth - 96cm
Height - 74,6cm
Weight - 13,1kg

Important

– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
0045 7668 8055 or e-mail: order@fl exa.dk
Issue 2 - 10/01/18
