Long Drawer
- St-Oil
Assembly Instructions
6338958
- Please keep for future reference
Dimensions
Length - 186cm
Depth - 91cm
Height - 21.5cm
Weight - 15kg
Important
– Please read these instructions fully before starting assembly
If you need help or have damaged or missing parts, call the Customer Helpline:
0045 7668 8055 or e-mail: order@fl exa.dk
Issue 1 - 15/05/14
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Argos St-Oil
Summary of Contents for Argos St-Oil
- Page 1 Long Drawer - St-Oil Assembly Instructions 6338958 - Please keep for future reference Dimensions Length - 186cm Depth - 91cm Height - 21.5cm Weight - 15kg Important – Please read these instructions fully before starting assembly If you need help or have damaged or missing parts, call the Customer Helpline: 0045 7668 8055 or e-mail: order@fl...
- Page 2 Safety and Care Advice Important – Please read these instructions fully before starting assembly • We do not • Check you have all the • Do not stand or put weight on recommend the components and tools listed on the product, this could cause use of power pages 2 and 3.
-
Page 3: Components - Parts
If you have damaged or missing components, Components - Parts call the Customer Helpline: 0045 7668 8055 Please check you have all the parts listed below Drawer side right x1 Drawer side left x1 Base list x2 (89.8x17.0x1.5cm) (89.8x17.0x1.5cm) (88.2x6.5x1.5cm) No. - Page 4 Components - Fittings Please check you have all the fi ttings listed below Note: The quantities below are the correct amount to complete the assembly. In some cases more fi ttings may be supplied than are required. No. 3901-40040 No. 3902-35015 No.
- Page 5 Assembly Instructions Step 1 Attach dowels to the drawer sides It may be necessary to tap the dowels in very gently with small hammer. Attach minifi x bolts the drawer front Step 2 Attach knobs to the drawer front with screws Step 3 Attach the drawer sides...
- Page 6 Assembly Instructions Step 4 Push the drawer base carefully into the grooves of drawer sides so that it is placed into the groove on the drawer front Step 5 Attach the drawer back to the drawer sides with the screws Step 6 Turn the drawer so that bottom side is up.
- Page 7 Assembly Instructions Step 7 Attach spacers to the front legs of your bed with screws Follow the measurements. Assembly is complete. 9 mm If you need help or have damaged or missing parts, call the Customer Helpline: 0045 7668 8055 E-mail: order@fl...
