- Page 1 Assembly Instructions Vacuum-Belt Applicator 5326C Made in Germany...
- Page 2 Edition: 12/2019 - Part No. 9009758 Copyright This documentation as well as translation hereof are property of cab Produkttechnik GmbH & Co. KG. The replication, conversion, duplication or divulgement of the whole manual or parts of it for other intentions than its original intended purpose demand the previous written authorization by cab.
-
Page 3: Table Of Contents
Table of Contents Introduction ............................4 Instructions ............................... 4 Intended Use ............................4 Safety Instructions ............................ 4 Safety Markings ............................5 Environment ............................. 5 Product Description ..........................6 Important Features ........................... 6 Technical Data ............................6 Overview ..............................7 Contents of Delivery ..........................8 Mounting .............................. -
Page 4: Introduction
• The device applicator mounted on a cab printer of the Hermes C series is intended exclusively for applying suitable materials that have been approved by the manufacturer. Any other use or use going beyond this shall be regarded as improper use. -
Page 5: Safety Markings
Introduction • In operation, moving parts are easily accessible. This applies especially for the zone, where the pad is moved between the starting and the labelling position. • During operation do not reach into that zone and keep long hair, loose clothes, and jewelry distant. Before any manipulations in those areas, close the shutoff valve. -
Page 6: Product Description
Attention Don't move the transport belt or - roller by hand or by an other outside power. Danger of destruction of the electronic control. • Technical Data Technical Data Vacuum-Belt Applicator 5326C Label width 46-174 label height 40-356 ¢ Product during labeling in motion ¢... -
Page 7: Overview
Product Description Overview Fig. 2 Device overview 1 SUB-D 15 Interface to the printer 6 Base plate for mounting on printer 2 Sensor 7 Control unit 3 Pressure roller 8 Screws to adjust the angle of the applicator 4 Screw roller 9 Mounting screws belt pulley 5 Fan 6x... -
Page 8: Contents Of Delivery
Product Description Contents of Delivery Fig. 3 Contents of delivery 1 Mounted applicator 2 Screws to connect the applicator to the printer 3 Documentation Note! Please keep the original packaging in case the applicator must be returned. Attention! The device and printing materials will be damaged by moisture and wetness. ... -
Page 9: Mounting
Mounting Fig. 4 Mounting applicator on printer Attention! Initiation, adjustments and changing of parts is to be performed by qualified service personal only. Initiation/Service Manual Applicators Attention! Disconnect the printer from the power supply before mounting the applicator! ... -
Page 10: Adjustments
Adjustments Note! The alignment of the applicator to the printer is set to the factory standard and should not be altered to ensure reliable label transportation. Only the Angle to the printer as well as the pinch roller should be adjusted. -
Page 11: Signals
Adjustments Waiting position of the label Label transport/Reflex sensor Fig. 6 In the setup menu the setting "Blow on" must be selected in order to change the parameter "Blow time". After reaching the reflex sensor (1) and detection point (3) the transportation device will continue for a set time to ensure the label (2) is transported to the pinch roller (4). -
Page 12: Operation
Operation Standard Operation Before commencing the labeling process check that the underlying connection are active. Load material. Ensure that the locking system is locked "Operator's Manual" of the printer. Switch on the printer. Press the feed key at the printer. A synchronization feed is initiated. -
Page 13: Error Messages
Error Messages Error Messages of the Printer For detailed information about printer errors (e.g. 'Paper out', 'Ribbon out', etc.) " Operator's manual" of the printer Error treatment: Clear the error result Press the feed key to synchronize the label feed, remove the excess labels manually ... -
Page 14: Licences
Person authorised to compile the technical file: Erwin Fascher Am Unterwege 18/20 99610 Sömmerda Signed for, and on behalf of the Manufacturer: Sömmerda, 08.07.2019 cab Produkttechnik Sömmerda Gesellschaft für Computer- und Automationsbausteine mbH Erwin Fascher 99610 Sömmerda Managing Director The product must not be put into service until the final machinery into which it is to be incorporated has been declared in conformity with the provisions of the Directive on machinery. -
Page 15: Eu Declaration Of Conformity
Annex II to Directive 2011/65/EU of the European Parliament and of the Council as regards the list of restricted substances Signed for, and on behalf of the Manufacturer: Sömmerda, 08.07.2019 cab Produkttechnik Sömmerda Gesellschaft für Computer- und Automationsbausteine mbH Erwin Fascher 99610 Sömmerda...
