  • Page 1 3G/HD/SD-SDI Quad-view Video Processor P/N: AV-GM08V3-S1...
  • Page 2: Table Of Contents

    However, like all electronic equipments, the AV-GM08V3-S1 should be used with care. Please read and follow the safety instructions to protect yourself from possible injury and to minimize the risk of damage to the unit.
  • Page 3: Introduction

    ● Software control through RS-232 or IP port. ● Control protocol available for customer proprietary design ● 1U size PACKAGE CONTENTS ● 1x AV-GM08V3-S1 ● 2x 1U rack mounting-ear ● 1x Installation software CD ● 1x UL 12V 5A power adapter ●...
  • Page 4: Specifications

    SPECIFICATIONS Model Name AV-GM08V3-S1 Technical Role of usage Multiplexer / video processor Dual output support Yes [DVI &SDI] Background video input DVI/HDMI [165MHz] Video bandwidth SDI 3G/HD/SD Video input support 480i / 576i / 720p / 1080i / 1080p Input TMDS signal 1.2 Volts [peak-to-peak]...
  • Page 5: Panel Descriptions

    PANEL DESCRIPTIONS Front Panel 1. Output Resolution Button: Select output resolution 2. Label Button: Window’s label ON/OFF 3. Custom Layout 1-8: Save custom layout button 4. IR Sensor: IR sensor for receiving the IR commands from IR remote 5. Default Layout mode A: Select default layout ( ) or custom layout 6.
  • Page 6 17. Input 1-4: SDI inputs 1-4 18. SDI local loop out...
  • Page 7: Hardware Installation

    3. Connect a device equipped with SDI output including SD/HD/3G to the BNC input connector of AV-GM08V3-S1. 4. Connect your computer with the AV-GM08V3-S1 by a 9-pin RS-232 cable or Cat.5e cable, and then install the software. 5. Plug in AD power cord into AC power socket.
  • Page 8: Connection Diagram

    CONNECTION DIAGRAM...
  • Page 9: Operation Software

    OPERATION SOFTWARE Method A: IR Remote Control Button Function Label Border & Label on/off Analog Clock Analog Clock on/off Digital Clock Digital Clock on/off Power on/off the device Custom layout 1 Custom layout 1 Custom layout 2 Custom layout 2 Custom layout 3 Custom layout 3 Custom layout 4...
  • Page 10 Method B: Software Control through RS-232 port / Ethernet port System Requirement and Precautions 1. The device provides a software control program, Quartet, which runs under Microsoft Windows 98, 2000, XP, Vista or 7 through the interface of RS-232 serial control. 2.
  • Page 11 Control Interface 1. PAP Panel Display and adjust the window size and position. Control percent: 10~100% panel  display/control size. Stretch: Fix the size ratio when the window is resizing.  PAP mode  Window 1 in full screen  Window 2 in full screen ...
  • Page 12 2. Tool Bar list: Status: Get all information of the device and update this software state. Port Setting: Pop-up the “Port Setting” dialog, user can change the connecting way. Advance Setting: Set the no signal color, fade in/out effect, background picture, window text, input text, OSD border, Clock, audio and factory reset.
  • Page 13 Clock and Audio:  User can set up the position of clock and other audio control. Factory Reset:  Click the button to do factory default reset. This default reset process will take about 10~15 seconds and it will be initialized all setting to original system state.
  • Page 14 Version: Read the software and firmware version. 3. Output Resolution: Set the output resolution. When setting the different resolution, the parameters of PAP and custom layout (position and size) will change accordingly.
  • Page 15 4. Audio, analog clock and digital clock 5. Background picture: 6. Default layout and Custom layout: Default layout: Use factory preloaded  video layouts. Custom layout: Use custom pre-saved video layouts.  In this part, you can adjust the size and position of output screen. If you want to save the layout, please right click to save this layout into device.
  • Page 16 8. Window setting Adjust the size, position or other settings of the specified window.
  • Page 17: Warranty

    The SELLER will NOT be liable for direct, indirect, incidental, special, or consequential damages resulting from any defect or omission in this manual, even if advised of the possibility of such damages. Also, the technical information contained herein regarding the AV-GM08V3-S1 features and specifications is subject to change without further notice.
