- Page 1 Product Code: 1030 OWNER’S MANUAL PRODUCT CODE: 1030 680kg ENGINE/TRANSMISSION LOAD LEVELLER Package Safe Working Load Engine Mount Points Weight Dimension 680kg 460 x 200 x 60mm 6kg Made in China to TQB Brands Pty Ltd specifications. Visit us at www.tqbbrands.com.au...
-
Page 2: Table Of Contents
Product Code: 1030 WARNING IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works. Failure to observe any of the instructions contained in the manual could result in severe personal injury to the user or bystanders, or cause damage to the equipment and property. Keep this manual in a convenient and safe place for future reference. -
Page 3: Safety Instructions
Product Code: 1030 SAFETY INSTRUCTIONS SAFETY OPERATING INSTRUCTIONS Before using the engine-transmission leveller ensure it is in sound condition, and ü good working order. Replace or repair damaged parts. Use recommended parts only. Non-authorised ü parts may be dangerous and will invalidate the warranty. Keep the engine-transmission leveller clean for best and safest performance. ü Locate the engine-transmission leveller in an adequate working area for its function, ü keep area clean and tidy and free from unrelated materials, and ensure there is adequate lighting. -
Page 4: Assembly, Operation, Preventitive Maintenance
Product Code: 1030 ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE 1. FEATURES The 1030 680kg engine-transmission leveller accepts a wide variety of engines and transmissions. This engine-transmission leveller comes with everything needed to perform work on your engine or transmission, including a steel beam, adjusting screw, steel chains with brackets, hooks and hardware. The engine-transmission leveller is specially designed to tilt the engine and/or transmission for easy removal/installation of most engines and transmissions. - Page 5 Product Code: 1030 4. STORAGE This engine-transmission leveller should always be stored in a dry location on a level surface. 5. MAINTENANCE Replace or repair damaged parts. Use recommended parts only. Non-authorised parts may be dangerous and will invalidate the warranty. Keep the engine-transmission leveller clean for best and safest performance. 6. SERVICE & REPAIR Any engine-transmission leveller found damaged in any way, or found to be worn or operates abnormally should be removed from service until repaired by an authorised service agent. Owners and / or operators should be aware that repair of this product may require specialised equipment and knowledge. Only authorised parts, labels and decals shall be used on this equipment. Annual inspection of the engine stand is recommended...
-
Page 6: Parts Diagram
Product Code: 1030 PARTS DIAGRAM PARTS LIST Part Description Qty Part Description Qty Lifting Chain Bolt M10x25 Bolt M12 x 40 Lock Nut M10 Lock nut M12 Cross Beam Washer Bolt M12x45 Connecting Plate Washer Sliding Block Shackle Threaded Bar Chain/Bracket Set Connecting Plate Bolt M10x35 Crank Arm Nut M10 Spring Pin Handle Washer Nut M6 Made in China to TQB Brands Pty Ltd specifications. Visit us at www.tqbbrands.com.au Page | 6... -
Page 7: Warranty
Product Code: 1030 WARRANTY Tradequip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase. - Page 8 Product Code: 1030 Another great product from TQB Brands now available from your nearest authorised TQB Brands distributor. TQB Brands Pty Ltd 1/40 Metrolink Circuit Campbellfield Victoria 3061 Email: sales@tqbbrands.com.au Made in China to TQB Brands Pty Ltd specifications. Visit us at www.tqbbrands.com.au Page | 8...
