09/21
Product Code: 2053T
About the TradeQuip brand
The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop
environment by professional users. With proven and trusted "Made for the Trade" reliability,
'TradeQuip' branded products offer the very best in performance for an affordable price. All backed
by a 1year trade guarantee across 1,000+ distributors Australia wide.
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au
Product Code: 2053T
TRANSMISSION
LIFTER
Specifications
•
Working Load Limit: 1,000kg
•
Maximum Height 1850mm
•
Minimum Height: 860mm
•
Cradle Size: 355L x 255W
•
Forward Tilt: 15°
•
Rearward Tilt 7°
•
Base Dimensions: 730 x 730mm
•
Nett Weight: 82kg
•
Carton: 560 x 390 x 820mm
•
Gross Weight: 89kg
GVM LESS THAN 3,200KG
Advertisement
Table of Contents
Related Manuals for TradeQuip 2053T
Summary of Contents for TradeQuip 2053T
- Page 1 The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop environment by professional users. With proven and trusted “Made for the Trade” reliability, 'TradeQuip' branded products offer the very best in performance for an affordable price. All backed by a 1year trade guarantee across 1,000+ distributors Australia wide.
-
Page 2: Table Of Contents
09/21 Product Code: 2053T WARNING IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works. - Page 3 09/21 Product Code: 2053T Made in China to TQB Brands Pty Ltd specifications Page Visit us at www.tqbbrands.com.au...
-
Page 4: Warning
09/21 Product Code: 2053T STANDARD OPERATING PROCEDURE DO NOT use this machine unless you have been trained and assessed to a competent level in its sate use and operation, and have been given permission to use this Long loose hair must be contained when operating... -
Page 5: Assembly, Operation, Preventitive Maintenance
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE 1. FEATURES The TradeQuip "Made for the Trade" 1,000kg Transmission Lifter is designed for transmission installation and removal. It features a universal mounting cradle that provides a wide fore and aft tilt range and a manually operated hydraulic system with smooth hydraulic lift and descent. - Page 6 09/21 Product Code: 2053T 5. INSPECTION • Prior to each use conduct a visual inspection checking for abnormal conditions, such as cracked welds, leaks, and damaged, loose, or missing parts. • The transmission lifter shall be maintained in accordance with the maintenance instructions. No alterations or modifications shall be made to this transmission lifter.
- Page 7 09/21 Product Code: 2053T Important: Dirt is the greatest single cause of failure in hydraulic units. Keep the transmission lifter clean and well lubricated to prevent foreign matter from entering the system. Pivots and pins in all manual pump and release mechanisms [marked X] should be lubricated with a Light Bearing Grease or 30/40W Machine Oil to ensure long life and prevent premature wear.
- Page 8 09/21 Product Code: 2053T TROUBLESHOOTING Problem Symptom Cause Conclusion Solution Lifter will not Pump has no Release pedal valve Valve seat/check ball Clean mechanism, lift using foot resistance, lift ram pin obstructed failure. bleed system, ensure pump will not raise all fasteners are tight.
-
Page 9: Parts Diagram
09/21 Product Code: 2053T PARTS DIAGRAM Made in China to TQB Brands Pty Ltd specifications Page Visit us at www.tqbbrands.com.au... -
Page 10: Parts List
WARRANTY TradeQuip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
