May-20
Product Code: 2056T
T
About the TradeQuip brand
The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop
environment
by
Trade" reliability, 'TradeQuip' branded products offer the very best in performance for an
affordable price. All backed by a 1year trade guarantee across 1,000+ distributors Australia wide.
professional
users.
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au
TRANSMISSION
Specifications
• Safe Working Capacity: 500kg
• Minimum Height: 855mm
• Maximum Height: 1760mm
• Cradle Size: 300 x 300mm
• Base Dimensions: 540 x 570mm
• Nett Weight: 31kg
• Carton: 1150 x 250 x 280mm
• Gross Weight: 37kg
With
proven
and
Product Code: 2056T
LIFTER
ENGINE CRANE
trusted "Made
for
the
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TradeQuip 2056T
Summary of Contents for TradeQuip 2056T
- Page 1 • Base Dimensions: 540 x 570mm • Nett Weight: 31kg • Carton: 1150 x 250 x 280mm • Gross Weight: 37kg About the TradeQuip brand The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop environment professional users. With proven trusted “Made...
-
Page 2: Table Of Contents
May-20 Product Code: 2056T WARNING IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works. -
Page 3: Standard Operating Procedure
May-20 Product Code: 2056T STANDARD OPERATING PROCEDURE DO NOT use this machine unless you have been trained and assessed to a competent level in its sate use and operation, and have been given permission to use this Long loose hair must be contained when operating... -
Page 4: Assembly, Operation, Preventitive Maintenance
If the pump still feels spongy or load is slow to raise, seek the services of a qualified Hydraulic repairer. *The TradeQuip range of transmission lifts use grade 32 Grade Hydraulic Oil for the correct operation and compatibility with the seals used in their construction. - Page 5 May-20 Product Code: 2056T 4. OPERATION Prior to use remove the Solid Plug and replace with the Air Vent Valve. NOTE: Follow the vehicle manufacturer's recommended procedures for removing the load as outlined in the vehicle service manual or repair guide.
- Page 6 May-20 Product Code: 2056T Periodic maintenance is essential for the efficient operation of Manual Transmission lifts. Pivots & Pins Pivots and pins around the hydraulic lift pump should be lubricated with a Light Bearing Grease or 30/40W Machine Oil to ensure long life and prevent premature wear.
-
Page 7: Troubleshooting
May-20 Product Code: 2056T TROUBLESHOOTING Problem Symptom Cause Conclusion Solution Lifter will not Pump has no Release handle valve Valve seat/check ball Bleed system as per lift using foot resistance, lift ram pin obstructed failure instructions pump will not raise... -
Page 8: Parts List
May-20 Product Code: 2056T PARTS LIST Part # Description Part # Description Spring Pedal Assembly Pump Piston Bush V-Ring Circlip Seal Washer O-Ring Nylon Castor Wheel Pump Unit O-Ring O-Ring Washer Screw Spring Cylinder Ball O-Ring Spring O-Ring Ball Cylinder... -
Page 9: Warranty
WARRANTY TradeQuip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
