Jan-24
Product Code: 2058T
WARNING
About the TradeQuip brand
The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop
environment
by
Trade" reliability, 'TradeQuip' branded products offer the very best in performance for an
affordable price. All backed by a 1year trade guarantee across 1,000+ distributors Australia wide.
A
professional
users.
Made in China to TQB Brands Pty Ltd specifications
Visit us at
Specifications
•
Safe Working Capacity: 500KG
•
Gross Weight: 37KG
•
Base Dimensions: 540x570 mm
•
Working Height: 1175-1985 mm
•
Lifting Platform Size:
A：362x362mm
B：Φ107.5mm
B
With
proven
and
www.tqbbrands.com.au
Product Code 2058T
AUXILIARY LIFTER
trusted "Made
for
the
Advertisement
Table of Contents
Related Manuals for TradeQuip 2058T
Summary of Contents for TradeQuip 2058T
-
Page 1: Warning
Working Height: 1175-1985 mm • Lifting Platform Size: A：362x362mm B：Φ107.5mm WARNING About the TradeQuip brand The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop environment professional users. With proven trusted “Made Trade” reliability, 'TradeQuip' branded products offer the very best in performance for an affordable price. -
Page 2: Table Of Contents
Jan-24 Product Code: 2058T WARNING IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works. -
Page 3: Standard Operating Procedure
Jan-24 Product Code: 2058T STANDARD OPERATING PROCEDURE DO NOT use this machine unless you have been trained and assessed to a competent level in its safe use and operation, and have been given permission to use this Safety glasses must be worn when operating this... -
Page 4: Assembly, Operation, Preventitive Maintenance
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE FEATURES This TradeQuip "Made for the Trade" 500kg Auxiliary Lifter is the perfect under hoist aid during removal and installation of small components. It features a mounting cradle and lift pad and a manually operated hydraulic system with smooth hydraulic lift and descent. - Page 5 Jan-24 Product Code: 2058T and secure. NOTE: Before lowering load check to ensure all tools and personnel are clear and it is safe to lower the load. 3. SLOWLY and CAREFULLY turn the release handle (02) to the right to lower the load to its lowest possible position.
- Page 6 Jan-24 Product Code: 2058T 5. To ensure best performance and longer equipment life, replace the complete hydraulic oil at least once a year. With jack in its lowest position, remove the air vent screw (22), lay the jack on its side and drain the oil into a suitable container.
-
Page 7: Troubleshooting
Jan-24 Product Code: 2058T TROUBLESHOOTING Trouble Cause Solution Unit fails to extend or 1.Refer to maintenance section and fill to 1.Low fluid level extends partially correct fluid level (7.4) 1.Low fluid level 1.Fill to correct fluid level (7.4) Incomplete or spongy 2.Refer to maintenance section and fill to... -
Page 8: Parts List
Jan-24 Product Code: 2058T PARTS LIST Made in China to TQB Brands Pty Ltd specifications Page 8 Visit us at www.tqbbrands.com.au... -
Page 9: Parts List Diagram
Jan-24 Product Code: 2058T PARTS LIST Part # Description Qty Part # Description Screw O-Ring Handle Washer Small Piston Handle Seat Spring Washer O-Ring Screw Big Piston Core Spring Seat Retainer Ring Spring Spring Cover Roller Dust Ring Foot Pedal... -
Page 10: Warranty
WARRANTY TradeQuip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
