01/24
Product Code: 6008T
About the TradeQuip brand
The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop
environment
by
Trade" reliability, 'TradeQuip' branded products offer the very best in performance for an affordable
price. All backed by a 1year trade guarantee across 1,000+ distributors Australia wide.
professional
users.
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au
SCISSOR LIFT
WORKSHOP TROLLEY
With
proven
and
Product Code: 6008T
Specifications
:
• Safe Working Capacity: 300kg
• Maximum Height: 1285mm
• Minimum Height: 350mm
• Table Size: 820(L) x 520(W)mm
trusted "Made
for
the
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TradeQuip 6008T
Summary of Contents for TradeQuip 6008T
- Page 1 • Safe Working Capacity: 300kg • Maximum Height: 1285mm • Minimum Height: 350mm • Table Size: 820(L) x 520(W)mm About the TradeQuip brand The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop environment professional users. With proven trusted “Made...
-
Page 2: Table Of Contents
01/24 Product Code: 6008T WARNING INFORMATION IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works. -
Page 3: Standard Operating Procedure
Ensure castor brakes are engaged when loading and unloading. • When servicing, use only TradeQuip identical replacement parts. Use of any other parts will void the warranty. • • Use the right product for the job. There are certain applications for which the Hydraulic Scissor Lift Trolley was designed. Do not modify the Hydraulic Scissor Lift Trolley and do not use the Hydraulic Scissor Lift Trolley for a purpose for which it was not intended. -
Page 4: Assembly, Operation, Preventitive Maintenance
The foot pump raises and lowers the platform using a single scissor lift and hydraulic cylinder. In addition, the TradeQuip 6008T can be used as a convenient mobile work bench so you can work at different heights to reduce the risk of injury. - Page 5 01/24 Product Code: 6008T 4. OPERATION Before placing anything on the Hydraulic Scissor Lift Trolley, lock the back two casters. The locking swivel castors can be locked by pressing the lever down into the locked position with your foot. Test the cart operation using the Foot Pedal and Control Lever (6).
-
Page 6: Parts Diagram (Table)
01/24 Product Code: 6008T PARTS DIAGRAM (TABLE) Made in China to TQB Brands Pty Ltd specifications Page 6 Visit us at www.tqbbrands.com.au... -
Page 7: Parts List (Table)
01/24 Product Code: 6008T PARTS LIST (TABLE) PART # DESCRIPTION PART # DESCRIPTION HANDLE TUBE LINK ROD PLATE FORM SCREW SPRING RETAINER RING SPRING CAP LIFTING ARM RELEASING HANDLE CONNECTION PLATE SAFETY BAR BOLT FOOT PEDAL ASSEMBLY WASHER COTTER PIN... -
Page 8: Parts Diagram (Pump)
01/24 Product Code: 6008T PARTS DIAGRAM (PUMP) Made in China to TQB Brands Pty Ltd specifications Page 8 Visit us at www.tqbbrands.com.au... -
Page 9: Parts List (Pump)
01/24 Product Code: 6008T PARTS LIST (PUMP) Part# Description Part# Description Screw O-Ring Valve Core Top Nut O-Ring Nylon Washer Spring Oil Tank Valve Seat Rubber Plug Copper Washer Seal Steel Ball Filter Spring Steel Ball Pump Base Spring Screw... -
Page 10: Warranty
WARRANTY TradeQuip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
