Feb-20
Product Code: 2002T
About the TradeQuip brand
The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop
environment
by
Trade" reliability, 'TradeQuip' branded products offer the very best in performance for an
affordable price. All backed by a 1year trade guarantee across 1,000+ distributors Australia wide.
professional
users.
Made in China to TQB Brands Pty Ltd specifications
Visit us at www.tqbbrands.com.au
TRANSMISSION
Specifications
• Safe Working Capacity: 500kg
• 2 Stage Lift
• Maximum Height: 1850 mm
• Minimum Height: 870mm
• Cradle Size: 362x250mm
• Forward Tilt: 15°
• Rearward Tilt: 7°
• Base Dimensions: 810 x 810mm
• Nett Weight: 73kg
• Carton: 560 x 390 x 890mm
• Gross Weight: 81kg
With
proven
and
Product Code: 2002T
LIFTER
trusted "Made
for
the
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TradeQuip 2002T
Summary of Contents for TradeQuip 2002T
- Page 1 • Base Dimensions: 810 x 810mm • Nett Weight: 73kg • Carton: 560 x 390 x 890mm • Gross Weight: 81kg About the TradeQuip brand The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop environment professional users. With proven trusted “Made...
- Page 2 Feb-20 Product Code: 2002T WARNING IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works.
- Page 3 DO NOT expose the telescopic transmission lifter to rain or any other kind of inclement weather. • When servicing, use only TradeQuip identical replacement parts. Use of any other parts will void the warranty. • Use the right product for the job. There are certain applications for which this Telescopic Transmission Lifter was designed.
- Page 4 ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE 1. FEATURES This 2-Stage telescopic hydraulic TradeQuip "Made for the Trade" Transmission Lifter offers a wide range of versatility designed to help increase workshop productivity. Designed for use with passenger car transmissions, the universal mounting cradle provides a wide fore and aft tilt range. A wide base is enhanced by four heavy-duty steel swivel castors and both a ring handle and a pull bar for easier manoeuvring throughout the workshop.
- Page 5 Feb-20 Product Code: 2002T 4. OPERATION Warning: Vehicle must be properly and adequately supported before commencing work with this telescopic transmission lifter. 1. The telescopic transmission lifter may easily be moved by gripping the ring handle and rolling it on its castors. Locate the transmission lifter under the transmission.
- Page 6 Feb-20 Product Code: 2002T 8. SERVICE & REPAIR Any transmission lifter is found damaged in any way, or found to be worn or operates abnormally it should be removed from service until repaired by an authorised service agent. Owners and / or operators should be aware that repair of this product may require specialised equipment and knowledge.
- Page 7 Feb-20 Product Code: 2002T PARTS LIST DIAGRAM Made in China to TQB Brands Pty Ltd specifications Page 7 Visit us at www.tqbbrands.com.au...
- Page 8 WARRANTY TradeQuip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
