TRANSMISSION LIFTER
Specifications
• Safe Working Capacity: 500kg
• Minimum Height: 855mm
• Maximum Height: 1760mm
• Cradle: 360x276mm
• Forward Tilt: 23°
• Backward Tilt: 16°
• Lateral Tilt: 7°
• Base Dimensions: 690 x 780mm
• Nett Weight: 61kg
• Carton: 550 x 270 x 780mm
• Gross Weight: 68kg
With
proven
and
Product Code: 2052
TELESCOPIC
:
trusted "Made
for
the
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for TradeQuip 2052
Summary of Contents for TradeQuip 2052
- Page 1 • Base Dimensions: 690 x 780mm • Nett Weight: 61kg • Carton: 550 x 270 x 780mm • Gross Weight: 68kg About the TradeQuip brand The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop environment professional users. With proven trusted “Made...
-
Page 2: Table Of Contents
May-20 Product Code: 2052 WARNING IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE WARNING The instructions and warnings contained in this manual should be read and understood before using or operating this equipment. Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough understanding of how this equipment works. -
Page 3: Standard Operating Procedure
May-20 Product Code: 2052 STANDARD OPERATING PROCEDURE DO NOT use this machine unless you have been trained and assessed to a competent level in its sate use and operation, and have been given permission to use this Long loose hair must be contained when operating... -
Page 4: Assembly, Operation, Preventitive Maintenance
If the pump still feels spongy or load is slow to raise, seek the services of a qualified Hydraulic repairer. *The TradeQuip range of transmission lifts use grade 32 Grade Hydraulic Oil for the correct operation and compatibility with the seals used in their construction. - Page 5 May-20 Product Code: 2052 4. OPERATION The Prior to use remove the Solid Plug and replace with the Air Vent Valve. NOTE: Follow the vehicle manufacturer's recommended procedures for removing the load as outlined in the vehicle service manual or repair guide.
- Page 6 May-20 Product Code: 2052 Important: Dirt is the greatest single cause of failure in hydraulic units. Keep the transmission lifter clean and well lubricated to prevent foreign matter from entering the system. Pivots and pins in all manual pump and release mechanisms [marked X] should be lubricated with a Light Bearing Grease or 30/40W Machine Oil to ensure long life and prevent premature wear.
-
Page 7: Troubleshooting
May-20 Product Code: 2052 TROUBLESHOOTING Problem Symptom Cause Conclusion Solution Lifter will not Pump has no Release pedal valve Dirt under release pin Hold pedal down and lift using foot resistance, lift ram pin obstructed retainer clean out pin cavity... -
Page 8: Parts List Components
May-20 Product Code: 2052 PARTS LIST COMPONENTS Part # Description Part # Description Wheel Stand M10 x25 Angled Bolt M12x70 Angled Bolt M10 Nut Washer Oil Tank Screw/Air Vent Valve Power Unit Foot Pedal Castor Wheel Release Valve Handle 12mm Lock Washer... -
Page 9: Parts List
May-20 Product Code: 2052 PARTS LIST Part # Description Part # Description Small Piston Rod Piston Spring Cylinder Bushing Washer O-Ring 12mm Snap Ring O-Ring Retainer Cover of Spring Oil Seal Piston Small Tank Nut Unit Ball Stopper Liner Bushing... -
Page 10: Warranty
WARRANTY TradeQuip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the guarantee period is ninety days from the date of purchase.
