Instructions for
Nomad Bed
Full
sku# 7962-NO-F

Parts:

N-75 BED RAIL (4)
N-24 REGULAR SLAT (16)
N-55 BED ENDS (2)
1
Use 2-1/2" Bolts (H-21) and
Cross Dowels (H-3) to attach
Bed Rails (N-75) and
Connector Slats (N-25).
Leave the bolts loose until Step 2.
2
Place Regular Slats (N-24) into the
pockets and then tighten the bolts.
Repeat Steps 1 and 2 for the other Bed Deck.
N-25 CONNECTOR SLAT (4)
NOTE:
Bolts should be just loose
enough to insert the Regular
Slats.
NOTE:
When the Slats are all in
their pockets, tighten the
bolts.
Manufactured by
394 Dairy Pak Rd. • Athens, GA 30607
kdframes.com • alan@kdframes.com
H A R D W A R E
H-1
3" BOLT
H-21 2 - 1/2" BOLT
H-3 CROSS DOWEL
H-10 HEX WRENCH
L I S T
16
8
24
1
H-3
H-21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Nomad Bed Full 7962-NO-F and is the answer not in the manual?

Questions and answers

Summary of Contents for kd frames Nomad Bed Full 7962-NO-F

  • Page 1 Instructions for Manufactured by Nomad Bed 394 Dairy Pak Rd. • Athens, GA 30607 Full kdframes.com • alan@kdframes.com sku# 7962-NO-F Parts: H A R D W A R E L I S T 3” BOLT H-21 2 - 1/2” BOLT H-3 CROSS DOWEL N-75 BED RAIL (4) H-10 HEX WRENCH...
  • Page 2 Use 3” Bolts (H-1) and Cross Dowels (H-3) to attach the decks to the Bed Ends with the rail pockets facing in. NOTE: Leave all bolts loose until both Bed Ends Rail pockets must are attached. Then tighten all bolts. face to the inside.
