- Page 1 ® RESmart BPAP System Service Manual...
-
Page 2: Table Of Contents
® Service Manual for RESmart BPAP V1.1 Table of Contents 1. Introduction ························································································································································· 1 1.1 Intended Use ··············································································································································· 1 I.2 Implement···················································································································································· 1 2. Structure······························································································································································ 1 2.1 Outer Illumination······································································································································· 1 2.2 Inner Construction······································································································································· 2 2.3 Spare Part···················································································································································· 2 3. Software ······························································································································································ 2 3.1 Instruction for Upgrading Device Software ·································································································... - Page 3 If applying this manual on other purpose, the validation should be confirmed by BMC Medical Co., Ltd. Other wise, BMC Medical Co., Ltd. has no responsibility for the result. All information in this manual is protected by law and regulation. All copyrights belong to BMC Medical Co., Ltd.
-
Page 4: Introduction
This device is not intended for life support. ® This service manual is used to help service people maintenance RESmart BPAP system of BMC Medical Co., Ltd. more efficiently. Instructions in this manual may help device work best. Engineer can find needed instruction from this manual quickly. -
Page 5: Inner Construction
Please remember the software version in the red frame. ® Power off the RESmart BPAP device, and then connect PC and the device via data cable. ® Run the software “BMC RESmart Tools for Upgrade” from PC and display as below: 2/18... -
Page 6: Hidden Function
® Service Manual for RESmart BPAP V1.1 Select the upgrade file which has same suffix letter as the machine version. (For example Version 1.88-TN should choose file name 1.98-TN) Select the right serial port, default is COM1. Click “OK”, display as below: Power on the BPAP device. -
Page 7: Malfunction And Countermeasure
® Service Manual for RESmart BPAP V1.1 patient information, but also Use Days and Use Time will be reset. Pressure calibration (Available on version 1.58 and later) Connect pressure meter to the air outlet of the device, in the Date and Time Setting menu, set ‘YYYY/MM/DD’=’2098/08/18’, press ‘Pressure Start/Stop Button’... -
Page 8: Malfunction Determination
® Service Manual for RESmart BPAP V1.1 4.2 Malfunction Determination 5/18... -
Page 9: Appendices
® Service Manual for RESmart BPAP V1.1 Appendices Appendix A: Device Configuration 1. Main device Fig. A - Main board (backside) Fig. B – Outlet (leftside) Hole #1, 2 and 3 in Fig. B, connect to sensor YL and LL via silicon rubber canal. Specified in Table 1: Fig. - Page 10 ® Service Manual for RESmart BPAP V1.1 Fig. C – Power PCBA (front side) Sockets figuration Fig. D – Wire connecting on power PCBA Fig. E – Power supply connecting 7/18...
-
Page 11: Humidifier
® Service Manual for RESmart BPAP V1.1 Fig. F – Power supply to humidifier Connecting relationship: Part Fig. Back of device Fig. C: CN1 Fig. C: CN2 Fig. A: P24 Fig. F: Left Fig. F: Right Blower 8-pin plug Fig. A: PM Table 2 2. - Page 12 ® Service Manual for RESmart BPAP V1.1 Fig. H – Power supply to humidifier Fig. I – Heater PCBA Connecting relationship: Part Fig. Fig. G: P2 Fig. G: P1 Fig. H: Left Fig. H: Right Table 3 9/18...
-
Page 13: Components Illumination
® Service Manual for RESmart BPAP V1.1 Components Illumination Device Inside Assembly Figure Insert humidifier locker on the shield bottom. Orange Black Insert humidifier power supply reed on the shield bottom as per Fig. E and F. Assembly the humidifier locker and button spring. - Page 14 ® Service Manual for RESmart BPAP V1.1 Assembly the foam pad (non-woven side up), the front and back foam blocks of the blower unit in the shied bottom. Align the location column of blower unit to the location port in the front block, Place the blower unit right between the front and back foam blocks in the shield bottom and lay it...
- Page 15 ® Service Manual for RESmart BPAP V1.1 1. Connect the air hole of the pressure sensor YL on the main board with the bottom hole(hole#1) in the front of the blower outlet with a canal of 12cm in length and 2mm in inner-diameter.
-
Page 16: Device Outside
® Service Manual for RESmart BPAP V1.1 2. Device Outside Assembly Figure Put handle in the socket on shield cover. Assembly handle fixing to handle and fix by screw (4×3mm*8mm). Assembly and fix the panel. Put on the key button. Assembly the infrared window, and put the shield cover on the bottom, adjust the position Infrared window... -
Page 17: Humidifier
® Service Manual for RESmart BPAP V1.1 Fix the shield by screws (4×M3*10mm). Device pad Stick four device pads. Put in filter and assembly the cover. Plug (up) Put on all plugs if necessary (without humidifier). Plug (down) Power plug 3. -
Page 18: Spare Part Configuration
® Service Manual for RESmart BPAP V1.1 Put spring on each of three poles on heater plane. Assembly the scaleboard on the heater plane and fix by screw (3mm*8mm). Scaleboard As per Table 3, assembly heater PCBA and wires. Put on light window. Assembly the inner and outer shield. - Page 19 ® Service Manual for RESmart BPAP V1.1 Shield Bottom Humidifier Clip Humidifier Locker Humidifier Fixing Filter Cover Shield Back Outlet PCBA Fixing Infrared Window Panel Humidifier Outer Shield 16/18...
-
Page 20: Spare Part List
® Service Manual for RESmart BPAP V1.1 Humidifier Inner Shield Light Window Pole Platelet Humidifier Power Plug Humidifier Plug (left-up) Humidifier Plug (left-down) Humidifier Plug (right-up) Humidifier Plug (right-down) Device Pad Humidifier Inner Connector Key Button Humidifier Scaleboard Heater Plane Spring Button Spring Spare Part List Part Name... - Page 21 ® Service Manual for RESmart BPAP V1.1 Power Supply PCBA 270031 PCBA Main Device Blower Unit 120069 Assembly Main Device Heater Plane 120006 Assembly Humidifier Power Supply PCBA Wire 120002 Wire Main Device Main Board PCBA Wire 120003 Wire Main Device Silicon Rubber Cap 220029 Assembly...
