RESmart GII BPAP System Y / U Series Quick Operation Manual V1.0
BPAP System Y / U Series Quick Operation Manual

1. Button Functions

Mute Button: Press it to mute the alert
Knob: Start treatment and adjust device settings
Ramp Button: Press it to enable the Ramp feature

2. Setting up the Device

Power Outlet
A. Connect one end of the tube to the assembled mask.
B. Connect the other end of the tube securely to the air outlet of the main device or of the
humidifier, as shown in the figure above.
C. Connect the power adapter to the DC inlet of the main device.
D. Connect the power cord to the power adapter.
E. Plug the power cord into the power outlet.

3. Adjusting Device Settings

A. After the device is connected to power, its screen displays the Main Interface shown in the first
figure below, or the Main Interface shown in the second figure
Note: The value of blood oxygen saturation (SpO
connected to the main device
The above interface only applies to U-20T, U-25T,
U-30T, U-30AT.
B. From the Main Interface shown above, press and hold the Ramp Button
The screen displays the Initial Setup Interface, as shown in the figure below.
A
Mask
Power Cord
Power Adapter
D
) and pulse rate can only be seen after the SpO
2
correctly.
1 / 2
Air Outlet of
the Humidifier
B
Air Outlet
Tube
C
C
C
C
Main Device
DC Inlet
below.
The above interface only applies to Y-20T, Y-25T,
Y-30T, Y-30AT.
Kit is
2
for three seconds.
