- Page 1 HYDRO SS 700 ► DIRECT FEED OPERATOR’S MANUAL NOTICE Read & Understand Retain for Future Reference...
- Page 2 Purchase Date Model ID Number Vendor Information Notes...
-
Page 3: General Safety
GENERAL SAFETY The Hydro SS 700 uses a high-speed component to atomize water, the following safety precautions must be observed at all times: Read operator’s manual carefully and thoroughly. Understand all safety warnings and instructions before attempting operation of the unit. Follow all local electrical and safety codes as well as the United States National Electrical Codes (NEC) and Occupational Safety and Health Act (OSHA). - Page 4 NOTIFICATION WARNING THE HYDRO SS 700 CAN BE AUTOMATED WHEN USED IN CONJUNCTION WITH A CONTROL. THE FAN MAY NOT APPEAR POWERED BUT COULD SUDDENLY BEGIN HIGH-SPEED ROTATION AS A FUNCTION OF THE PRESET CONTROL. WARNING HIGH-SPEED ROTATION, NEVER OPERATE UNIT WITHOUT THE HOUSING AND SAFETY GUARDS INSTALLED.
- Page 5 HANGING GUIDELINES Where to Locate NOTE: THIS UNIT IS SPECIFICALLY DESIGNED TO BE HUNG Mount the fan high overhead in the largest available open area. As a general rule, the higher the better when mounting your fan. Allow one foot above the unit and adequate room in front of and below the fan for the unobstructed propulsion of the fog.
- Page 6 POSITIONING Small Structures In applications requiring only one unit, install the unit anywhere along one end wall, propelling the fog upward and Controller location area horizontally down the length of the structure. If there is forced ventilation, choose the intake end of the structure.
-
Page 7: Installation
INSTALLATION Hanging the Unit After unpacking, locate or install a sturdy horizontal Fig. 1 support capable of handling over 20 pounds of weight. If the support is a 3/4 - 1” pipe, use the optional U-bolt packet provided. For the universal mounting bolt attached, drill a 5/16”... -
Page 8: Water Solenoid
Lubricate Motor: Remove two blue plugs at the top of the motor. Apply 4-5 drops of light grade petroleum based oil at each bearing location 1 to 2 times a year or as needed. Replace blue plugs. See Fig. 4 Cleaning Blade Assembly: After removing the blade assembly, remove the stainless plate and O-ring. -
Page 9: Troubleshooting
TROUBLESHOOTING Issue Corrective Action INITIAL START-UP 1. Fan Blade Does Not Spin 1. Check power supply. If using a controller, try bypassing it and plug unit directly into a power outlet. Check for a faulty power cord. 2. No Fog but Blade Spins 2. - Page 10 Fan Blade Assembly First remove the atomizing ring/front guard assembly. The blade assembly is now accessible and is secured to the motor shaft with a setscrew. Loosen the setscrew using 1/16” Allen wrench (provided) and carefully leverage blade assembly off the shaft. See Fig.
-
Page 11: Part Identification
PART IDENTIFICATION DESCRIPTION PART NO. Atomizing Ring 400-001 Front Guard 400-002 Motor 115V 400-110 Rear Guard 400-127 Blade Assembly 400-128 Housing 400-100 SST Hanger a-620 Water Feed Tube 400-130 Pivot Location 10 Drain Barb Fitting 400-114 11 Drain Hose 400-089 12 Flowmeter Panel a-F-5 13 In-Line Strainer... - Page 12 IMITED ARRANTY Aquafog and accessories are warranted to the original purchaser against defects in material and workmanship under normal use for one full year from date of purchase. Any part determined to be defective and returned to the manufacturer, shipping cost prepaid, will be repaired or replaced at Jaybird Manufacturing, Inc.'s discretion without charge.
