- Page 1 HYDRO SS 700 ► BENCH TOP ► HANGING SUMP OPERATOR’S MANUAL NOTICE Read & Understand Retain for Future Reference...
- Page 2 (See installation). Keep hands and all objects from entering the path of the blade. Install the Hydro SS 700 at bench-top height or higher for added safety and optimum performance. Do not use flammable liquids, caustic materials, or corrosive materials with the Hydro SS 700.
- Page 3 PLACEMENT & LAYOUT Placement Guidelines Mount the fan high overhead in the largest available open area. As a general rule, the higher the better when mounting your fan. Allow one foot above the unit and adequate room in front of and below the fan for the unobstructed propulsion of the fog.
- Page 4 INSTALLATION & OPERATION Installation Find a Suitable Location: For Bench Tops, find a stable, flat surface. For Hanging Sumps, locate a support capable of handling over 25 pounds. Drill a 5/16” clearance hole through the support where you want to hang the unit. Using 1/2” wrenches, secure the unit Fig.
- Page 5 MAINTENANCE Lubricate Motor: Remove two blue plugs at the top of the motor. Apply 4-5 drops of light grade petroleum based oil at each bearing location 1 to 2 times a year or as needed. Replace blue plugs. See Fig. 4 Clean Pump and Sump: Periodically clean debris from inside the sump area and nearby the pump.
- Page 6 10-24 Flange Nuts Fig. 7 Fan Blade Assembly First remove the atomizing ring/front guard assembly. The blade assembly is press-fitted onto the motor shaft. Position fingers behind both sides of the hub with forearms pressed up against the rim of the housing. Use the housing’s rim as leverage and pull the blade assembly outward towards the front.
- Page 7 REPLACEMENT PART IDENTIFICATION DESCRIPTION PART NO. BENCH TOP MODEL Atomizing Ring 400-001 Front Guard 400-002 Motor 1/20hp 115V 400-110 Rear Guard 400-127 Blade Assembly 400-128 Housing 400-100 Hanger Assembly 400-129 SST Water Feed Tube 400-130 Pivot Location Sump 400-131 Float Valve Assembly 400-132 Flow Control Valve 400-016...
- Page 8 IMITED ARRANTY Aquafog and accessories are warranted to the original purchaser against defects in material and workmanship under normal use for one full year from date of purchase. Any part determined to be defective and returned to the manufacturer, shipping cost prepaid, will be repaired or replaced at Jaybird Manufacturing, Inc.'s discretion without charge.
