- Page 1 XE MOBILE ATOMIZER USER'S MANUAL AND OPERATING INSTRUCTIONS XE ORSM MODEL o ORSM-1000 o ORSM-1500 OPERATOR'S MANUAL NOTICE Read & Understand Retain for Future Reference...
-
Page 2: Safety Guidelines
Troubleshooting ....7 - 8 DEATH OR SERIOUS INJURY. Aquafog Fan Exploded View ..9 - 10 WARNING INDICATES A WARNING ORSM Tank Exploded View . - Page 3 ENERAL AFETY Since the mobile ORSM uses high-speed components to atomize liquids, the following safety DANGER HIGH-SPEED ROTATION precautions must be observed at all times: 1. Read all manuals included A motionless atomizer may with this product. Be familiar appear safe, but its blade with the product and controls.
- Page 4 ETTING TARTED NPACKING HECKLIST LECTRICAL DO NOT OPERATE UNIT IF GROUND FAULT RECEPTACLES WARNING WARNING DAMAGED DURING SHIPPING, ARE RECOMMENDED AND MAY HANDLING OR USE. DAMAGE MAY RESULT IN BREAKAGE BE REQUIRED BY LOCAL AND/OR NATIONAL CODE. AND CAUSE INJURY OR PROPERTY DAMAGE. USE OF AN EXTENSION CORD IS NOTICE Un-crate carefully and position ORSM on...
-
Page 7: Troubleshooting
ROUBLESHOOTING BEFORE INSPECTION AND/OR SERVICE WARNING DISCONNECT AND LOCK OUT POWER SOURCE. 1. Poor/Inconsistent Fogging Output A.) Inconsistent or spotty chemical coverage usually occurs because the fog volume output is too high. Ideally, fog will disappear when fogging at rates near 3 GPH. To check for fog volume output, refer to Maximum Pre-set Flow Rate (See Page 6). -
Page 8: Troubleshooting ( Cont .)
ROUBLESHOOTING CONT BEFORE INSPECTION AND /OR SERVICE WARNING DISCONNECT AND LOCK OUT POWER SOURCE. 4. No Fog A.) The self-priming system will usually take about 10 seconds before you see fog output. Check to see if the flow control valve is open. The valve is open when the handle is down. B.) Check the pre-set flow rate valve located inside the tank (refer to page 6 Factory Pre-set Flow Valve). -
Page 9: Aquafog Fan Exploded View
QUAFOG XPLODED DENTIFICATION ID # Description Qty/Unit Housing Safety guard SST feed tube Liquid feed tube fitting Drain fitting 1/4" x 1" fender washer SST Fan motor (specify Model) Pinned venturi assembly Fan blade assembly (specify Model) Rear guard Fan blade (specify Model) SST Face plate &... -
Page 12: Part Identification
DENTIFICATION... -
Page 13: Maintenance
5. Storage Protect your mobile Aquafog from winter damage. Expansion due to freezing can burst the fittings or the internal feed pump. If storing unit in below freezing temperatures, be sure all fluid is drained from the tank area. Damage due to freezing is not covered under warranty. -
Page 14: Warranty
IMITED ARRANTY Aquafog and accessories are warranted to the original purchaser against defects in material and workmanship under normal use for one full year from date of purchase. Any part determined to be defective and returned to the manufacturer, shipping cost prepaid, will be repaired or replaced at Jaybird Manufacturing, Inc.'s discretion without charge.
