- Page 1 GT-500-HS ATOMIZER USER'S MANUAL AND OPERATING INSTRUCTIONS GT 500-HS HANGING SUMP UNIT o 115V 60Hz o 240V 50Hz UL and CSA Electrical Components OPERATOR'S MANUAL NOTICE Read & Understand Retain for Future Reference www.JigglyGreenhouse.com | (800) 878-7829 | Sales@JigglyGreenhouse.com...
-
Page 2: Table Of Contents
ABLE OF ONTENTS ESCRIPTION Aquafog units are intended to condition large volumes of air using water or other non-hazardous PAGE liquids at air temperatures between 33ºF and 160ºF. General Safety ...... -
Page 3: General Safety
ENERAL AFETY Since the GT 500-HS uses high-speed components to atomize liquids, the following safety precautions DANGER HIGH-SPEED ROTATION must be observed at all times: 1. Read all manuals included A motionless atomizer may with this product. Be familiar appear safe, but its blade with the product and controls. -
Page 4: Common Setups
Atomized Product www.JigglyGreenhouse.com | (800) 878-7829 | Sales@JigglyGreenhouse.com... -
Page 5: Placement
LACEMENT Placement Guidelines TO HANG THE UNIT, USE A LEVEL 1" PIPE OR DRILLABLE FLAT NOTICE AREA ABLE TO SUPPORT OVER 30 LBS. Mount the fan high overhead. Allow room in front of and below the fan for the unobstructed propulsion of fog. Rule of thumb: the higher the better, but mount at least three feet away from any roofing structures. - Page 6 LACEMENT CONT Large Structures, Natural Ventilation In large structures with natural ventilation, propel fog the length of the structure with the first fan row no more than 25' from the end wall. The first fan should be: > > > >...
-
Page 7: Unpacking / Installation
www.JigglyGreenhouse.com | (800) 878-7829 | Sales@JigglyGreenhouse.com... -
Page 8: Pivot / Utilities
www.JigglyGreenhouse.com | (800) 878-7829 | Sales@JigglyGreenhouse.com... -
Page 9: Power Connection
www.JigglyGreenhouse.com | (800) 878-7829 | Sales@JigglyGreenhouse.com... -
Page 10: Operation
PERATION BEFORE TESTING FAN MAKE SURE ALL OBJECTS ARE OUT OF THE DANGER ROTATION PATH OF THE FAN BLADES. HIGH-SPEED WARNING. KEEP HANDS CLEAR! MAKE SURE GUARDS ARE INSTALLED OR UNIT IS OUT OF REACH. BUMP START GT 500-HS and check for proper fan blade rotation (clockwise if looking at front of unit). -
Page 11: Troubleshooting
ROUBLESHOOTING BEFORE INSPECTION AND/OR SERVICE WARNING DISCONNECT AND LOCK OUT POWER SOURCE. 1. Fan Does Not Operate A.) Check voltage requirements on unit and electrical supply. Check for live receptacle, plug, power line and unit's power On/Off switch. B.) Look for any loose connections inside the main motor's junction box. 2. - Page 12 ROUBLESHOOTING CONT BEFORE INSPECTION AND/OR SERVICE WARNING DISCONNECT AND LOCK OUT POWER SOURCE. 6. Fan Motor Becomes Excessively Hot The main fan motor normally becomes very hot to the touch. However, if it gets so hot that it begins to smell or smoke or the power cord becomes hot, discontinue operation and consult an electrician to properly evaluate the problem.
-
Page 13: Gt 500-Hs Exploded View
www.JigglyGreenhouse.com | (800) 878-7829 | Sales@JigglyGreenhouse.com... - Page 14 www.JigglyGreenhouse.com | (800) 878-7829 | Sales@JigglyGreenhouse.com...
-
Page 15: Part Identification List
(GT 500-HS) DENTIFICATION ID # Description Qty per Unit ID # Description Qty per Unit GT 500 COMPONENTS Drain fitting Blade tip set screw 13-500 GT wash down duty motor Reservoir O-Ring Pinned venturi assembly SST Reservoir plate Rear guard Motor plate PLS 1/4"... -
Page 16: Oscillator Exploded View
SCILLATOR XPLODED 3 6 0 www.JigglyGreenhouse.com | (800) 878-7829 | Sales@JigglyGreenhouse.com... -
Page 17: Maintenance
5. Storage 2. Flush Out Tank Protect your Aquafog from winter damage. The tank should be rinsed regularly, especially Expansion due to freezing can burst fittings, if using chemicals. Remove drain plug solenoids and flowmeters. -
Page 18: Warranty
IMITED ARRANTY Aquafog and accessories are warranted to the original purchaser against defects in material and workmanship under normal use for one full year from date of purchase. Any part determined to be defective and returned to the manufacturer, shipping cost prepaid, will be repaired or replaced at Jaybird Manufacturing, Inc.'s discretion without charge.
