Koldwave 6CC10BEA2AA00 Owner's Manual

Modular multi air conditioner
Hide thumbs Also See for 6CC10BEA2AA00:
Table of Contents

Advertisement

Quick Links

Download this manual
WPC-15000
WMC-2500
Owner's Manual
Please read and save these instructions. Read carefully before attempting to assemble, install, oper-
ate or maintain the product described.
Protect yourself and others by observing all safety information. Failure to comply with instructions
could result in personal injury and property damage! Retain instructions for future reference.
Modular Multi Air Conditioner
Descripti on
Koldwave Modular Multi Air conditi oner feature multi -functi on spot cooler providing various ac-
cessories available to fi t customer needs. This Unit is used to spot cooling for large areas where
cooling of the enti re area is not practi cal or possible. A dedicated spot cooling thermostat controls
the unit in this applicati on. This Unit can also be used in smaller areas for room cooling.
A control panel provides ease of use and contains a self-diagnosti c functi on and display, showing
operati ng modes, room and set temperatures, and faults, If an abnormal operati on occurs, a visual
display of the fault is shown.
Suitable applicati ons include :
a factory or work place, computer rooms, emergency cooling, etc..
Unpacking
Aft er unpacking the unit, carefully inspect unit for any damage that may have occurred during
transit. Check for any loose, missing or damaged parts.
1
Owner's Manual
Owner's Manual
6CC10BEA2AA00
6CC10BEA2AA00
Figure 1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 6CC10BEA2AA00 and is the answer not in the manual?

Questions and answers

Related Manuals for Koldwave 6CC10BEA2AA00

Summary of Contents for Koldwave 6CC10BEA2AA00

  • Page 1 Figure 1 Descripti on Koldwave Modular Multi Air conditi oner feature multi -functi on spot cooler providing various ac- cessories available to fi t customer needs. This Unit is used to spot cooling for large areas where cooling of the enti re area is not practi cal or possible. A dedicated spot cooling thermostat controls the unit in this applicati on.

  • Page 2: Table Of Contents

    6CC10BEA2AA00 Owner’s Manual Table of Contents SPECIFICATION.....................4 GENERAL SAFETY INFORMATION..............4APPLICATIONS....................6 Portable Server Rack Mounted, Hang Stack ASSEMBLY (STANDARD)................7 Component Parts Power Cord Holder ASSEMBLY (PORTABLE).................8 Component Parts Handle Cool air duct assembly Caster ASSEMBLY (SERVER RACK)................9 Component Parts Universal adjust...
  • Page 3 Power Cord Holder 1 pcs Drain hose (20ft length) 1 pcs * The 6CC10BEA2AA00 is used in conjunction with various accessories to adapt to your environmental needs. These accessories (Portable Kit, Server Rack Kit, Hanging Kit, Stack Kit) are sold separately to allow you to customize the 6CC10BEA2AA00 to your specific...

  • Page 4: Specification

    6CC10BEA2AA00 Owner’s Manual Specifications Cooling Capaci- Power Consump- Rated Cur- EER Btu/ Model No. Power Supply Ph-V-Hz ty Btu/h tion Watts rent Amps 6CC10BEA2AA00 Single Phase, 115V, 60Hz 10,000 1000 10.0 Power Cord Power Cord Length Dimensions Model No. Nema Plug Gauge AWG W x D x H - in.
  • Page 5 6CC10BEA2AA00 Owner’s Manual 7. DO NOT cover or obstruct the unit’s inlet and outlet grilles. 8. DO NOT use the unit in areas where it will be exposed to rain or water. 9. NEVER unplug the while it is operating.

  • Page 6: 4Applications

    - This unit can be stacked on top of each other to produce a capacity of 20,000BTU or 30,000 BTU in same area. It allows you to stack 6CC10BEA2AA00 up to 3 high. You can enjoy space efficien- cy and bigger cooling capacity.

  • Page 7: Assembly (Standard)

    6CC10BEA2AA00 Owner’s Manual ASSEMBLY (Standard) COMPONENT PARTS Display /Control Panel Cool Air Outlet Evaporator / Filter Figure 2 - front and Right Side View Exhaust Air Outlet Electrical Access Drain Pump Hose Panel Connector Power cord Figure 3 - rear and...

  • Page 8: Assembly (Portable)

    6CC10BEA2AA00 Owner’s Manual ASSEMBLY (Portable) COMPONENT PARTS Handle Cool air duct Caster Figure 5 - portable kit attachment Figure 6 - handle Figure 7 - cool air duct attachment assy attachment HANDLE COOL AIR DUCT ASSEMBLY 1. Take out the handle 2 pcs from the accesso- 1.

  • Page 9: Assembly (Server Rack)

    6CC10BEA2AA00 Owner’s Manual ASSEMBLY (Server Rack) COMPONENT PARTS Rack diffuser Universal adjust * See Figure 19 on page 12. Rack assembly Figure 9 - server rack kit attachment Figure 10 - installation in 19” server rack RACK ASSEMBLY 1. Assemble the rack assembly parts 1set (6ea) to fit in server rack.

  • Page 10: Assembly (Mounted, Hang)

    6CC10BEA2AA00 Owner’s Manual ASSEMBLY (Mounted, Hang) COMPONENT PARTS Condenser intake air outlet Eva intake air outlet Figure 14 - Rear and Figure 13 - Front and Left Side View Right Side View CONDENSER INTAKE AIR DUCT FLANGE 1. Remove condenser intake air duct flange (includ- ed filter) 1 pcs from carton.
  • Page 11 Removing the power supply cord and permanently connection the unit should be per- formed only by a qualified electrician. 6CC10BEA2AA00 is heavy.(121lbs) A minimum of 2 people are required to lift the unit. When hanging and permanently connecting the unit all applicable local/state/federal building codes must be followed.

  • Page 12: Assembly (Stack)

    6CC10BEA2AA00 Owner’s Manual ASSEMBLY (Stack) COMPONENT PARTS Figure 19 - universal adjust attachment UNIVERSAL ADJUST 1. Take out the universal adjust 4 pcs from the acces- sory box. 2. Place the universal adjust on the base panel of unit. 3. Install on the unit as shown in Figure 19.

  • Page 13: Installation Guide

    NOTE: Make sure the AC outlet is free of dirt, dust, oil, water, or any other foreign material. The unit is equipped with an approved NEMA plug configuration. (6CC10BEA2AA00: 5-15P) The appropriate outlet must be used for each plug type.

  • Page 14: Operation

    6CC10BEA2AA00 Owner’s Manual Operation CONTROL PANEL Figure 8 1. POWER BUTTON: Activates unit when POWER BUTTON is pressed. (Fan starts on low speed). If power button is pressed during operation, unit stops. 2. BLOW BUTTON: Changes fan speed from 1)low, 2)high, 3) Auto when pressed.
  • Page 15 6CC10BEA2AA00 Owner’s Manual 8. TARGET: Displays Target Temperature and Humidity set by pressing button +/- respectively. 9. ALARM: Alarm indicator lights(blinks) and indicates abnormal system operation. If Alarm occurs, compressor stops. System operation stops when ALARM light is activated(blinks) longer than 3 minutes.

  • Page 16: Maintenance

    6CC10BEA2AA00 Owner’s Manual Maintenance FILTER CLEANING (Without flange) There are 2 filters in the unit. The evaporator filter is located at the front of the unit. The con- denser filter is located at the rear of the unit. 1. Open the front grill.
  • Page 17 6CC10BEA2AA00 Owner’s Manual FILTER CLEANING (With flange) 1. Loosen up 2 bolts on flange. 2. Slide filter up and use vacuum cleaner to remove the dust from the filter. 3. If the filter is heavily covered with dust and dirt, warm water and mild soap or neutral deter- gent may be used to wash the filter.
  • Page 18 6CC10BEA2AA00 Owner’s Manual Product Portable Air Conditioner Customer: Please read and keep this Model No. manual for future reference and keep Date of Purchase sales receipt as proof of purchase. Place of Purchase Serial No. Period of Warranty SELF-DIAGNOSTIC CODES...
  • Page 19 6CC10BEA2AA00 Owner’s Manual SELF-DIAGNOSTIC ALARM CODES Alarm Display Problem Cause Corrective Action • Do not use the air Frost prevention • Indoor heat exchanger conditioner if ambient sensor and temperature too low temperature is lower Abnormal • TH3 temperature than 18°C (64°F)

  • Page 20: Wiring Diagram

    6CC10BEA2AA00 Owner’s Manual Wiring Diagram WMC-2500 CD3.31 HIGH SPOT/COOL PRESSURE SWITCH Power Remote ALARM Control (Option) CURRENT TARGET TEMP/HUMID TEMP/HUMID DRAIN PUMP POWER BLOWER COOL DEHUMID COM CO SEN1 OUT_TEMP SENSOR SEN2 IN_TEMP SENSOR SEN3 ICE_TEMP SENSOR IR/FU IN_HUMIDITY SENSOR...

  • Page 21: Troubleshooting

    6CC10BEA2AA00 Owner’s Manual Troubleshooting chart Symptom Possible Cause(s) Corrective Action 1. Check the power supply 1. Reset the circuit breaker and to verify that power is restart the unit available to the unit The unit doesn’t work 2. Verify that the power 2.

  • Page 22: Obtaining Service

    The serial number of the unit. c. Where and when the unit was purchased. d. All of the model information about your Koldwave Portable Air Conditioner. e. Any information on the failure, including LED’s that may or may not be illuminated.
  • Page 23 6CC10BEA2AA00 Owner’s Manual For Koldwave warranty please visit http://koldwave.com/html/literature.asp...
  • Page 24 6CC10BEA2AA00 Owner’s Manual KOLDWAVE 125 North Elm St. Westfield, Ma 01085, USA PH: 252-753-1921 Fax: 252-753-1953 www.koldwave.com Printed in August, 2019...
