AIRMASTER
PORTABLE
AIR-COOLED
AIR CONDITIONER
INSTALLATION &
OPERATION
MANUAL
GENERAL DESCRIPTION ..................................... 1
PRODUCT DATA AND SPECIFICATIONS ......... 2, 3
UNIT DESCRIPTION
Standard Features ............................................... 4-7
General Air Flow Patterns ....................................... 7
ACCESSORIES ................................................. 8-13
APPLICATIONS ............................................... 14-15
SERVICE
Installation ............................................................. 15
Checkout of Unit .................................................... 16
Troubleshooting Guide ..................................... 16-18
Inspection and Repair ...................................... 19-21
Parts Replacement Procedure ......................... 21-23
Preventative Maintenance ..................................... 24
Piping Schematic .................................................. 25
Wiring Diagram (Logic and Interconnecting) .... 26-27
Unit Drawing .......................................................... 28
PARTS LIST ..................................................... 29-30
WARRANTY ......................................................... 31
260 NORTH ELM STREET • WESTFIELD, MA 01085 • Tel No. (413) 564-5520 • Fax No. (413) 564-5815
5211 CREEKBANK ROAD • MISSISSAUGA, ONTARIO L4W 1R3 CANADA • Tel No. (905) 625-2991 • Fax No. (905) 625-6610
GENERAL DESCRIPTION
The Koldwave Airmaster is a portable air-cooled zone
cooler which directs cool air to specific areas or
objects through four, adjustable, four-way grilles. Many
small computer and telephone rooms, tanning bed
rooms, laboratories, factories, and numerous areas
can be cooled by its indicated cooling capacity. The
Koldwave Airmaster can also be used for back-up
cooling or as an emergency stand-by unit.
The cord-connected Koldwave Airmaster is provided
with heavy-duty casters. The swivel casters provide
handling ease for convenient relocation. This unit is
completely self-contained with the entire refrigeration
system, electrical components, condenser and
evaporator housed in an attractively-designed, painted
metal cabinet.
NOMENCLATURE
2 A K 10 1 1
Series
Air Cooled
Koldwave
2AKSM-3
42-9134 Rev. 4
1 = 115 Volt
Single Phase
Capacity Indicator
