Owner's Manual
Please read and save this manual. Read carefully before attempting to assemble, install, operate or maintain
the product described.
Protect yourself and others by observing all safety information. Failure to comply with manual could result in
personal injury and/or property damage! Retain manual for future reference.
Features
Koldwave 6SS12BEA2ACA0 / 6SS24BGA2ACA0 are designed for a fast installation
and start up. The split systems are designed for applications where ducting condenser
discharge air is not practical. The outdoor unit removes condenser heat through a glycol
loop and can be located up to 30ft away from the indoor unit. The units do not require
an external water source. All glycol/water mixture is provided with the unit. With 2 fan
speeds the indoor units allow for quiet operation for office settings or any application
where noise can be a factor. With their durable metal construction and 4 wheels, they
are very useful for rental. Integral control panel has troubleshooting features and clear
indications of unit operation. The units have a "spot cool" or "room cool" functions. The
spot cool is designed to deliver very cold air for a continuous amount of time. The room
cool feature is designed to work with a set-point based on room air. The unit will turn on
and off by an integral return air sensor.
Typical Uses
Computer server rooms, Tents, Offices, Events Marquees, Warehouses, Military uses, Commercial kitchens,
Hospitals, Schools, Reception areas

Specifications

Model
Cooling Capacity
6SS12BEA2ACA0
12,000BTU (3.5kW)
6SS24BGA2ACA0
22,000BTU (6.5kW)
Depth/Width/
Model
Height/Weight
(Indoor Unit)
27.75 / 13.77 /
6SS12BEA2ACA0
36.5 inch
/183Lbs
27.75 / 13.77 /
6SS24BGA2ACA0
36.5 inch
/205Lbs
NOTE: Refrigerant and Electrical supply can be different per country. Please check the label on the unit for
proper information.
6SS12BEA2ACA0 / 6SS24BGA2ACA0
Split Portable

Air Conditioner

Refrigerant
Electrical Supply
R410A (1.2 lbs)
115V, 1phase, 60hz
R410A (1.61 lbs)
220V, 1phase, 60hz
Depth/Width/
Height/Weight
Fan Speeds
(Outdoor Unit)
26 / 10.82 /
25.78 inch
2
/ 48.5Lbs
27.6 / 10.82 /
27.8 inch
2
/ 59.5Lbs
1
Rated Current
Amps
12.3A
12.3A
Noise Level at 3m
Air Flow (high/low)
(Indoor Unit, high/low)
258 / 219 CFM
40 / 36 dBA
653 / 565 CFM
58 / 54 dBA
SP-IOM-1
6SS12BEA2ACA0/
6SS24BGA2ACA0
Figure 1
Operating Range
64-113°F (18-45°C)
64-113°F (18-45°C)
Control
Integral
Integral
