- Page 1 Operating Instructions PBM-4K-H Series PBM-210-4K-H PBM-4K-H Series PBM-217-4K-H PBM-221-4K-H PBM-224-4K-H PBM-232-4K-H PBM-247-4K-H PBM-255-4K-H...
-
Page 2: Table Of Contents
Users’ Manual: PBM-4K-H Series Table of Contents PRECAUTION ------------------------------------------------------------------------------------------------- 5 OVERVIEW----------------------------------------------------------------------------------------------- 8 ADVANCED FEATURES --------------------------------------------------------------------------------- 8 FUNCTIONAL EXPLANATION OF EACH PART-------------------------------------------------------- 9 -------------------------------------------------------------------------------------------- 9 RONT ANEL PBM-224-4K-H -------------------------------------------------------------------------------------- 9 Front Keys Arrangements -------------------------------------------------------------------------- 9 Front Keys Operations ----------------------------------------------------------------------------- 10 ... - Page 3 Users’ Manual: PBM-4K-H Series -------------------------------------------------------------------------- 16 OLOR EMPERATURE ONTROL --------------------------------------------------------------------------------------------------- 16 ------------------------------------------------------------------------------------------ 16 SPECT ATIO ------------------------------------------------------------------------------------- 17 ----------------------------------------------------------------------------------------- 17 EAKING ILTER ------------------------------------------------------------------------------------------- 17 ALSE OLOR HDR M -------------------------------------------------------------------------------------------- 18 ------------------------------------------------------------------------------------------- 18 AMERA AUDIO MENU OPTIONS ------------------------------------------------------------------------------ 18 SDI / SFP O...
- Page 4 Users’ Manual: PBM-4K-H Series Config LAN2/Ember+------------------------------------------------------------------------------ 26 Protocol Setting------------------------------------------------------------------------------------ 26 Set ID ----------------------------------------------------------------------------------------------- 26 Fan Control----------------------------------------------------------------------------------------- 27 ---------------------------------------------------------------- 27 APTION ORTH MERICAN ARKET ----------------------------------------------------------------------------------------- 27 UTPUT ANGE ------------------------------------------------------------------------------------------- 28 IDEO ANGE --------------------------------------------------------------------------------------------- 28 AVEFORM 13. OSD TREE ----------------------------------------------------------------------------------------------- 29...
-
Page 5: Precaution
Users’ Manual: PBM-4K-H Series Precaution B efore operati ng thi s unit, please read this m anual carefully. WARNING: To reduce the risk of any electric shock, please do not remove the back cover. No user serviceable parts inside. Refer any service matters to qualified service personnel. - Page 6 This product should be moved with care. Quick stops, excessive force and uneven surfaces may cause the product damages. A ccessories Do not use accessories not recommended by PLURA Inc. as they may cause hazards. V entilation Do not block any of the ventilation openings.
- Page 7 Users’ Manual: PBM-4K-H Series Upon completion of any service or repairs to this product, ask the service technician to perform safety checks to determine that the product is in proper operating condition and the warranty seal is provided. 18. M ounting The product should be mounted on a wall as recommended in the instructions.
-
Page 8: Overview
THE NEW PBM-4K-H AFFORDABLE AND COMPREHENSIVE SERIES. The PBM-4K-H series is our latest portfolio of 4K monitors that is capable to decode and preview a wide range of signal standards in 4K, UHD, FHD and HD standards. The PBM-4K-H was introduced in alignment with increased industry demand for an affordable yet comprehensive 4K monitor series. -
Page 9: Functional Explanation Of Each Part
Users’ Manual: PBM-4K-H Series 3. Functional explanation of each part 1. Front Panel PBM-224-4K-H Tally LED Headphone Speaker Front Key Front Keys Arrangements Page 9 of 36... -
Page 10: Front Keys Operations
Users’ Manual: PBM-4K-H Series Front Keys Operations Key Name Operation ► Power ON/OFF Button. STANDBY ► Select SDI 1. SDI 1 SDI 2 ► Select SDI 2. ► Select HDMI. HDMI ► Select SFP1, SFP2. ► Select COMPONENT. COMPONENT CVBS ►... -
Page 11: Rear Panel
Users’ Manual: PBM-4K-H Series 2. Rear Panel Connection Details DC Battery IN PIN NO Description 2 , 3 DC IN 12V DC IN 12V for PBM-210-4K-H, PBM-217- 4K-H, PBM-221-4K-H & PBM-224-4K-H RJ-45 – GPI, Control LAN 1 & Control LAN 2 (Ember+) ... -
Page 12: Interface Description
Users’ Manual: PBM-4K-H Series Contact Point Switch It is possible to attach pin one by one. GND Terminal: 8 Pin of RJ-45 Interface description Interface Description SDI 1 IN 12G/3G/HD/SD SDI SDI 1 OUT SDI 2 IN 3G/HD/SD SDI... -
Page 13: Menu Overview
Users’ Manual: PBM-4K-H Series 4. MENU OVERVIEW In this system menu, there are several ways to maneuver the menu settings. Most menus consist of three levels to select the necessary option, but some settings require greater depth. If you press the MENU button, the first and second level of the menu system will appear on the monitor screen. -
Page 14: On Screen Menus Selection And Adjustment
Users’ Manual: PBM-4K-H Series 6. On Screen Menus Selection and Adjustment 1. How to adjust the OSD screen 1. Press the MENU button and then UP/DOWN button to select each menu. button and then use UP/DOWN (SEL/INPUT)/MENU button to display the available 2. -
Page 15: Select Video Input
Users’ Manual: PBM-4K-H Series 7. SELECT VIDEO INPUT 1. How to Select Video Source by OSD 1. Press the SET/INPUT button and then UP/DOWN button to select the required video source. 2. Press the SET/INPUT button to go to select the desired video source. -
Page 16: Adjust
Users’ Manual: PBM-4K-H Series 1. Adjust - Adjust the values of Brightness, Contrast, Color, Tint and Sharpness directly from -50 to 50 2. Color Temperature Control - For Setting the Color temperature or adjusting RGB gain value - User (User setting RGB gain value), VAR(3200K ~ 9300K), Often used value( 9300K, 6500K, 5400K,3200K) and 3D LUT Calibration value(D-Cinema 6302K) - Color Space: Native/BT.709/D-Cinema... -
Page 17: Mono/Blue Only
Users’ Manual: PBM-4K-H Series - Full Screen, 16:9, 4:3, 14:9, 13:9, 1.85:1: The video will displayed with based on the selected aspect ratio. - Function key can be assigned to the aspect ratio and will be rotating through this sequence, Pixel to Pixel, Full Screen, 16:9, 4:3, 14:9, 13:9, 1.85:1, 2.35:1... -
Page 18: Hdr Mode
Users’ Manual: PBM-4K-H Series 8. HDR Mode - ST 2084-300 / ST 2084-1000 / ST 2084-10000 / HLG 9. Camera Log - Off, SLog3 To LC-709,Slog3 To LC-709TypeA, Slog3 To Slog2-709, Slog3 To Cine+709, Slog2 To LC-709, Slog To LC-709TypeA, Slog2 To Slog2-709, Slog2 To Cine+709, User - Import User Log: User may import a custom log LUT from a USB memory stick to the monitor. -
Page 19: Level Meter
Users’ Manual: PBM-4K-H Series - Select primary or secondary audio group to extract. (Group 1~4) - Audio output channel source select. (Channel1~4, Channel1/2, Channel3/4, off) 2. Level Meter - Display the audio level meter on screen in SDI input. -Pair: Respectively By Audio Pair (L&R) display -Group: Respectively By Audio Group display - Level Meter Scale mode selects. -
Page 20: Volume
Users’ Manual: PBM-4K-H Series 3. Volume - Adjust the speaker or headphone Volume level. (0~32) 10. Marker MENU OPTIONS Page 20 of 36... -
Page 21: Marker & User Marker
Users’ Manual: PBM-4K-H Series 1. Marker & User Marker - Marker: 16:9, 4:3, 14:9, 13:9, 1.85:1, 2.35:1, 1.85:1&4:3, User1, User2, User3 (Customized markers). - User Marker: The user defined Marker size setting. 2. Safety Area -Safety Area: Draw dotted line Marker screen. -
Page 22: Preset 1 & Preset
Users’ Manual: PBM-4K-H Series 6. Preset1 & Preset2 - Markers can be set as preset 1 & 2 and be triggered by GPI controller. - GPI preset markers can only be utilized by GPI controller 11. GPI MENU OPTIONS 1. GPI Control & GPI# - For programming selected functions to particular GPI ports. -
Page 23: Setup Menu Options
Users’ Manual: PBM-4K-H Series 12. SETUP MENU OPTIONS 1. Factory Default - Factory: User Reset. - Setup Load: Load user saved values or default value - Setup Save: Save user setting values at user 1, 2, 3. 2. Function 1 ~6 - Function 1~6: Select the required function to be allocated to the FUNCTION Keys 1, 2, 3, 4, 5, 6. -
Page 24: On Screen Display
Users’ Manual: PBM-4K-H Series Marker size Select Marker size Safety Marker size Select Safety Marker size Marker Prese1/2 Marker Preset 1/2 on/off Waveform Waveform on/off Peaking Peaking on/off False Color False Color on/off UMD on/off Caption Caption on/off HDR on/off... -
Page 25: Under Monitor Display (Color: Tally R/G Mode Action )
Users’ Manual: PBM-4K-H Series Under Monitor Display (color: Tally R/G mode action ) Channel-12 Channel-12 Channel-12 Tally Red Tally Green UMD: UMD display on/off UMD Character: UMD Character Select UMD Position: UMD display positions select (L-T, C-T, R-T, L-B, C-B, R-B) ... -
Page 26: Screen Control
- Internal Pattern Auto Run, White, RED, Green, Blue, Yellow, Cyan, Magenta Config LAN1 -Plura System Controller (PSC-400) Network setting. DHCP: DHCP on/off (Manual IP settings – DHCP on) * “Apply” to confirm all settings were applied. Config LAN2/Ember+ ... -
Page 27: Fan Control
Users’ Manual: PBM-4K-H Series Fan Control Fan Control: Internal Fan Control option based on temperature sensor Auto / force on / force off Fan Active Temperature: Adjusts fan based on temperature in Celsius degree. ONLY applicable when the Fan Control setting is set to Auto. -
Page 28: Video Range
Users’ Manual: PBM-4K-H Series 7. Video Range -Range Check: on/off. -Y Max: Maximum luminance level. -Y Min: Minimum luminance level. -C Max: Maximum chroma level. -C Min: Minimum chroma level. -Color: Black/Blue/Red/Green -Grid: Grid line on/off -Blink: Y/C Min-Max to blink. (0~7) 8. -
Page 29: Osd Tree
Users’ Manual: PBM-4K-H Series 13. OSD TREE Page 29 of 36... -
Page 30: Video
Users’ Manual: PBM-4K-H Series 1. Video Page 30 of 36... -
Page 31: Audio
Users’ Manual: PBM-4K-H Series 2. Audio Page 31 of 36... -
Page 32: Marker
Users’ Manual: PBM-4K-H Series 3. Marker Page 32 of 36... -
Page 33: Gpi
Users’ Manual: PBM-4K-H Series 4. GPI Page 33 of 36... -
Page 34: Setup
Users’ Manual: PBM-4K-H Series 5. Setup Page 34 of 36... -
Page 35: Mechanical Dimension
Users’ Manual: PBM-4K-H Series 14. Mechanical Dimension PBM-224-4K-H *AutoCad.dwg available upon request Page 35 of 36... - Page 36 www.plur ainc .com U.S.A. Germany U.A.E. S.Korea Page 36 of 36...
