Precision Medical Live Active Five Replacement Instructions

Sieve Bed
1
Assembly
Replacement
Instructions
4
bed assembly, and slide it into the
300 Held Drive
Northampton, PA 18067
Register the Sieve Bed Assembly in the Concentrator
precisionmedical.com
Press and hold the Audio Pause button to enter the menu. Press the 5 button to navigate to the Sieve Beds
1-800-272-7285
option. Press the 3 button to select the Sieve Beds option. Press the 3 button again to register the sieve bed
assembly. "Done" will appear on the screen once completed. Press the Audio Pause button to exit the menu.
Turn concentrator off, and
remove the battery and external
power from unit.
Remove 4 plugs from new sieve
concentrator.
2
Turn unit upside down, and place
on soft surface. Remove screws
and bottom cover
5
Gently push until sieve bed
replacement is fully seated, flush
with bottom surface. Replace bottom
cover and secure screws.
3
Pull upward on the Pull String Loop
while holding the device down to
remove sieve bed assembly.
6
Turn unit upright and insert
battery. Gently push until battery
is locked in place.
