Precision Medical Live Active Five Setup Manual

Set-Up Guide
Instructions
1. Plug AC Power Supply Jack
into Charger Base.
2. Connect AC Power Cord into
AC Power Adapter.
3. Plug AC Power Cord into AC
Wall Outlet.
4. Insert Battery into Charger
Base.
• Light ON - Charging
• Light OFF - Fully charged
Charge Time
Battery charge time is
approximately 3.5 hours.
Do not open the Charger Base or power
supply case. There are no serviceable
parts inside.
Do not expose the Charger Base or
power supply to water or conductive
liquids.
Replace Battery if it fails to charge or
if you notice a substantial decrease in
product run time.
Inspect the AC Power Cord for signs of
damage. Discontinue use and replace if
damaged.
Use only the AC Power Adapter with AC
Power Cord (508699) provided with the
Battery Charger Kit.
CAUTION
Battery Charger
Battery
Battery Charger
Light ON - When Charging
Light OFF - Fully Charged
Charger Base
AC Power Adapter
Ordering Information
Battery Charger
(battery not included)
Battery Charger Bundle
(includes battery)
AC Power Adapter
with AC Power Cord
Battery
DC Car Adapter
AC Wall Outlet
AC Power Cord
508649
508650
508699
508561
506750
