Input Terminals; Figure 1-14 Connector Terminals - Keysight U1271A User Manual

Introduction 1

Input terminals

The terminal connections for the different measurement functions of your
multimeter are described in the table below. Observe the rotary switch position of
your multimeter before connecting the test leads to the connector terminals.
Ensure that the terminal connections are correct for that particular
WARNING
measurement function before starting any measurement.
To avoid damaging this device, do not exceed the rated input limit.
CAUTION
Figure 1-14 Connector terminals
Keysight U1271A/U1272A User's Guide 51
