- Page 1 User Manual USC-250 Ubiquitous Service Computer ® with 15" TFT LCD and Intel Core™ i5 6300U/i3 6100U/ ® Celeron 3955U Processor...
- Page 2 The documentation and the software included with this product are copyrighted 2019 by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to improve the products described in this manual at any time without notice. No part of this manual may be reproduced, copied, translated, or transmitted in any form or by any means without the prior written permission of Advantech Co., Ltd.
- Page 3 To assist us in improving this manual, we welcome any comments and constructive criticisms. Please send all feedback in writing to “support@advantech.com”. Technical Support and Assistance Visit the Advantech website at http://support.advantech.com to obtain the latest product information. Contact your distributor, sales representative, or Advantech's customer service center for technical support if you need additional assistance.
- Page 4 In accordance with the IEC 704-1:1982 specifications, the sound pressure level at the operator position does not exceed 70 dB (A). DISCLAIMER: These instructions are provided according to the IEC 704-1 specifica- tions. Advantech disclaims all responsibility for the accuracy of any statements con- tained herein. USC-250 User Manual...
- Page 5 Do not touch any components on the CPU card or other cards while the device is powered on. Disconnect the power before making any configuration changes. The sudden rush of power after connecting a jumper or installing a card may damage sensi- tive electronic components. USC-250 User Manual...
- Page 6 USC-250 User Manual...
-
Page 7: Table Of Contents
Contents Chapter General Information ......1 Introduction ....................2 Device Layout ................... 2 Specifications .................... 3 1.3.1 General ..................3 1.3.2 Ethernet ..................3 1.3.3 Power Requirements ..............3 1.3.4 Miscellaneous ................3 1.3.5 Environment.................. 3 1.3.6 Physical Characteristics..............3 Dimensions ....................4 Chapter System Setup ........5... - Page 8 USC-250 User Manual viii...
-
Page 9: Chapter 1 General Information
Chapter General Information This chapter provides basic information regarding USC-250. Introduction Device Layout Specifications Dimensions... -
Page 10: Introduction
1.1 Introduction Advantech’s USC-250 ubiquitous service computer is the latest addition to its Avalo product family. Powered by a 6th generation Intel® Core™ i5 6300U/i3 6100U/Cel- eron® 3955U processor that delivers high-performance computing, the USC-250 fea- tures a 15” TFT LCD panel and ultra-slim form factor for easy installation in limited- space environments. -
Page 11: Specifications
Storage Temperature: -40 ~ 60 °C (-40 ~ 140 °F) Relative Humidity: 90% @ 40 °C (non-condensing) 1.3.6 Physical Characteristics Dimensions (W x H x D): 352 x 316 x 240 mm (13.85 x 12.44 x 9.44 in) Weight: 5.2 kg (11.46 lb) USC-250 User Manual... -
Page 12: Dimensions
1.4 Dimensions USC-250 User Manual... -
Page 13: Chapter 2 System Setup
Chapter System Setup This chapter details the system setup process for USC-250. Initial Setup Jumper Settings RAM/Storage Installation Peripheral Installation Dual Display Touch Settings... -
Page 14: Initial Setup
Pin 1-2: Normal (default), Pin 2-3: Clear CMOS JP_CASHV1: Pin 1-2: 12 V, Pin 2-3: 24 V CN24: (This jumper allows users to set the COM port power mode) Default: RI This Note: PCB silkscreen “ ▽ ”mark Pin 1. create space USC-250 User Manual... -
Page 15: Ram/Storage Installation
2.3 RAM/Storage Installation Remove the rear cover and cable cover. Install the RAM and M.2 2242 storage. Replace the cable cover and rear cover. This white content USC-250 User Manual... -
Page 16: Peripheral Installation
At the rear of the device on the left side is the peripheral socket. Insert the desired peripheral module into the socket. Secure the module in place using two screws. 2.4.2 VESA Mount Installation Install the VESA bracket onto the device and secure in place using two screws. USC-250 User Manual... -
Page 17: Rear-Mounted Screen Installation
2.4.3 Rear-Mounted Screen Installation Remove the rear cover and cable cover. Install the screen module at the rear of the USC-250 device and secure in place using two screws. Adjust the angle of the rear-mounted display screen. USC-250 User Manual... -
Page 18: Avalo Secondary Display Installation
2.4.4 Avalo Secondary Display Installation Assemble the tube stand and secondary display. Attach the USC-250 device to the tube stand and secure in place using screws. 2.4.5 Vacuum Florescent Display (VFD) Installation Remove the rear cover and cable cover. USC-250 User Manual... - Page 19 Connect the cables to the VFD module and the I/O port on the USC-250 device. Install the VFD module and secure in place using screws. Replace the cable cover and rear cover. USC-250 User Manual...
-
Page 20: Barcode Scanner Installation
A barcode scanner module can be installed at the bottom or the right side of the USC-250 device. To install at the bottom of the device, simply attach the bar- code scanner module to the device (as shown below) and secure in place using screws. -
Page 21: Dual Display Touch Settings
To configure the touch control function, follow the instructions provided below. Access the Control Panel, and click on “Tablet PC Settings”. From the drop-down menu (1), select the device to configure. Double click the <Setup> button (2). USC-250 User Manual... - Page 22 The message shown below will be displayed on the USC-250 screen. Touch the screen to confirm the touch function. If a secondary display is integrated with the USC-250 device and it supports touch control, repeat Steps 2 and 3 to configure the touch function of the secondary display.
-
Page 23: Chapter 3 Bios Setup
Chapter BIOS Setup... -
Page 24: Introduction
In most cases, the USC-250 device will have been setup and configured by the dealer or systems integrator prior to delivery. However, some of the BIOS settings may need adjustment to set the system configuration data, such as the current date and time, or type of hard drive installed. -
Page 25: Main Menu
3.2.1 Main Menu Press <Del> or <Esc> to enter the AMI BIOS CMOS Setup Utility. The Main Menu will appear onscreen as shown below. Use the arrow keys to select among the items and press <Enter> to accept or enter the sub-menu. The Main BIOS setup screen has two main frames. -
Page 26: Advanced Bios Features
3.2.2 Advanced BIOS Features Select the Advanced tab from the BIOS setup menu to enter the Advanced BIOS setup screen. Users can select any of the items in the left frame of the screen, such as CPU Configuration, to access the sub-menu for that item. Display an Advanced BIOS setup option by highlighting it using the <Arrow>... - Page 27 3.2.2.2 PCH-FW Configuration 3.2.2.3 ACPI Settings Enable ACPI Auto Configuration [Disabled] This item allows users to enable or disable BIOS ACPI auto configuration. Enable Hibernation [Enabled] This item allows users to enable or disable hibernation. This option may be not available with some OS.
- Page 28 3.2.2.4 NCT6106D Super IO Configuration Serial Port 1 Configuration Serial Port 2 Configuration USC-250User Manual...
- Page 29 Serial Port 3 Configuration Serial Port 4 Configuration USC-250User Manual...
- Page 30 Serial Port 5 Configuration Parallel Port Configuration USC-250User Manual...
- Page 31 3.2.2.5 Hardware Monitor 3.2.2.6 S5 RTC Wake Settings USC-250User Manual...
- Page 32 3.2.2.7 USB Configuration USC-250User Manual...
- Page 33 Legacy USB Support [Enabled] This item allows users to enable or disable legacy USB support. The Auto option disables legacy support if no USB devices are connected. XHCI Hand-Off [Enabled] USB Mass Storage Driver Support [Enabled] Mass Storage Devices [Auto] This item shows USB mass storage device information.
- Page 34 3.2.2.9 CSM Configuration USC-250User Manual...
- Page 35 Note: If the Windows OS is set to UEFI mode, the storage and video settings must be configured as “UEFI”. USC-250User Manual...
-
Page 36: Chipset Configuration
3.2.3 Chipset Configuration Select the Chipset tab of the BIOS main menu to enter the Chipset setup screen. Users can select any item in the left frame of the screen. The Chipset screens are shown below. The sub-menus are shown in the following pages. USC-250User Manual... - Page 37 USC-250User Manual...
- Page 38 USC-250User Manual...
- Page 39 Restore AC Power Loss [Power Off] This item allows users to specify what state to go to when power is re-applied after a power failure (G3 state). Wake On LAN [Enable] This item allows users to enable or disable Wake on LAN function. 3.2.3.1 SATA Configuration USC-250User Manual...
- Page 40 USC-250User Manual...
- Page 41 3.2.3.2 RAID Setup Configuration For SATA mode configuration, selection “RAID”. Note: If Windows is set to legacy mode, configure RST Legacy OROM to “enabled”. Save and exit the BIOS. Reboot the system. Then press <Ctrl + I> to access RAID setup.
- Page 42 Note: If Windows is set to UEFI mode, configure the Boot Option Filter to “UEFI only”, and ensure the storage and video settings are configured as “UEFI”. Save and exit the BIOS. Reboot the system and access the BIOS Setup Utility. Then navigate to the Advanced tab and select the “Intel Rapid Storage Technology”...
- Page 43 USC-250User Manual...
- Page 44 USC-250User Manual...
- Page 45 USC-250User Manual...
- Page 46 USC-250User Manual...
-
Page 47: Security Configuration
3.2.4 Security Configuration Administrator Password This item allows users to set the administrator password. Click on the item and type in the password and then press <Enter> to set the administrator password. User Password This item allows users to set the user password. Click on the item and type in the password and then press <Enter>... -
Page 48: Save & Exit Configuration
Setup Prompt Timeout This item allows users to configure the number of seconds that the system waits for a setup activation key. Use the <+> and <-> keys to adjust the number of seconds to wait for setup activation key.65535 (0xFFFF) means indefinite wait- ing. - Page 49 USC-250User Manual...
- Page 50 No part of this publication may be reproduced in any form or by any means, such as electronically, by photocopying, recording, or otherwise, without prior written permission from the publisher. All brand and product names are trademarks or registered trademarks of their respective companies. © Advantech Co., Ltd. 2019...
