Jumpking JK7524TBG User Manual

88inch / 2.24m 7.5ft hexagonal combo trampoline and enclosure with toss ball game
Hide thumbs

Advertisement

Quick Links

Download this manual
TRAMPOLINE AND ENCLOSURE
Warning
Read the assembly, installation,
care,maintenance, and use
instructions in this manual prior
to assembling and using this
trampoline/enclosure.Save this
manual for future reference.
Warning
Recommended for use by children above 3 years of age.
Maximum weight limit: 180lbs(82kgs). Do not exceed the weight limit recommended
by the manufacturer.
Please read all of the direction prior to assembly. Do not apply excess force during
assembly. Assemble only with adult supervision. Use gloves to protect your hands
from pinch points and sharp points during assembly.
Warning! Not suitable for children under 36 months. Small parts and long cords may
be a choking and strangulation hazard.
88INCH / 2.24M
7.5FT HEXAGONAL COMBO
WITH TOSS BALL GAME
USER'S MANUAL . . . . . . . . . . . . 3
Assembly, Installation, Care,
Maintenance, and Use Instructions.
YJ USA Corp.,
3970 Lindbergh Drive
Addison, TX 75001
Customer Hotline: 1-877-927-8777
www.jumppod.com
www.jumpking.com
Model: JK7524TBG

Advertisement

loading
Need help?

Need help?

Do you have a question about the JK7524TBG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Jumpking JK7524TBG

Summary of Contents for Jumpking JK7524TBG

  • Page 1 88INCH / 2.24M 7.5FT HEXAGONAL COMBO TRAMPOLINE AND ENCLOSURE WITH TOSS BALL GAME Model: JK7524TBG Warning USER’S MANUAL ... . 3 Read the assembly, installation, care,maintenance, and use Assembly, Installation, Care,...
  • Page 2 ２...
  • Page 3 7.5FT HEXAGONAL COMBO TRAMPOLINE AND ENCLOSURE WITH TOSS BALL GAME Model: JK7524TBG...
  • Page 4 WARNING: This product is intended for use by children above 3 years of age. This enclosure is to be used only in connection with this trampoline. Read and follow all warnings and instruction. This product is intended to be assembled by an adult. Maximum weight limited 82kg/180lbs.
  • Page 5 ASSEMBLY TRAMPOLINE/ENCLOSURE PLACEMENT IMPORTANT ASSEMBLY INFORMATION A Phillips Head screw driver is needed to 1. Place the trampoline/enclosure on a level surface assemble trampoline/enclosure. However, a before use. screwdriver is not provided. Assembly requires two persons. Keep 3. Use the trampoline/enclosure in a well-lit children away from the trampoline/enclosure until it is fully assembled.
  • Page 6 2. Note: This step requires two people. During this step, you will connect the six leg sec- tions. Hold the leg sections in the positions shown. Insert the top tube into the POD-connector. Repeat this step until all six leg sections are connected.
  • Page 7 4. Lay the Frame Pad (6) on the frame. Adjust the position of the Frame Pad so the notches are aligned with the Legs (3) as shown. Be sure 6 Enclosure Frame Openings are fitted to the POD-connector position. Do not use the trampoline without the Frame Pad (6), which is designed to reduce the likeli- hood of injury to the user from coming in con- tact with the trampoline frame.
  • Page 8 You will require a screwdriver (not included) to complete assembly. Do not allow use of the trampoline during assembly. 4 sets Enclosure You will now assemble the Safety Enclosure poles 9, 10. for your trampoline. 2 sets Take the Enclosure Bottom curve poles(9), Enclosure Enclosure Top curve poles(10), poles 11,...
  • Page 9 Spread the Netting (15) on the trampoline bed. Find the ROD on top of enclosure netting. Stand on the trampoline and insert one of the exposed sections of the Black G4 pole into a plastic grip on top of one of the enclosure tubes. Attach the others exposed sections of the RODs to the other enclosure tubes in the order shown in the diagram.
  • Page 10 Note: During steps 10 and 11, you will “sew” the lower edge of the netting(15) to the V-ring and webbing loop on the bed using the cords(19). Locate the V-ring closest to the door. Thread one end of a cord(19) through the lower edge of the Webbing loop netting(15) above the V-ring and then thread the cord through the V-ring.

  • Page 11: Care And Maintenance

    CARE AND MAINTENANCE Care sleeves. - punctures, frays, tears, or holes worn in the bed, frame Do not allow pets or animals on the trampoline or pad, netting, foam sleeves. inside the enclosure, as claws may snag and pull the - deterioration in the stitching or fabric of the bed, frame bed material or damage the frame pad or netting.

  • Page 12: Exploded Drawing And Part List

    Warning! Not suitable for children under 36 months. Small parts and long cords may be a choking and strangulation hazard. YJ USA Corp., 3970 Lindbergh Drive Addison, TX 75001 Customer Hotline: 1-877-927-8777 www.jumppod.com www.jumpking.com Qty. Description Qty. Description Enclosure Middle straight poles Top Tube with POD-connector...
