RUGGEDCOM RSL910
Installation Guide
Communication Ports
The RUGGEDCOM RSL910 can be equipped with various types of communication ports to enhance its abilities and
performance.
Figure 12: Port Assignment
1. Ports 7 and 8 2. Ports 1 to 6 3. Port 9 and 10
Port
1 to 6
7 and 8
9 and 10
CONTENTS
•
Section 4.1, "Copper Ethernet Ports"
•
Section 4.2, "EoVDSL Ports"
•
Section 4.3, "SFP Transceivers"
1
2
Copper Ethernet Ports (10/100Base-TX)
SFP Transceivers (1000Base-TX/BX/FX/SX/LX)
Universal EoVDSL Ports
Communication Ports
3
Type
Chapter 4
21
