Chapter 2
Installing the Device
IMPORTANT!
The user is responsible for the operating environment of the device, including maintaining the integrity
of all protective conductor connections and checking equipment ratings. Make sure to review all
operating and installation instructions before commissioning or performing maintenance on the
device.
1.
Review the relevant certification information for any regulatory requirements. For more information, refer to
Section 6.1,
"Approvals".
2.
Mount the device.
3.
Connect the failsafe alarm relay.
4.
Connect power to the device and ground the device to safety Earth.
5.
Connect the device to the network.
6.
Configure the device.
Section 2.2
Unpacking the Device
When unpacking the device, do the following:
1.
Inspect the package for damage before opening it.
2.
Visually inspect each item in the package for any physical damage.
3.
Verify all items are included.
IMPORTANT!
If any item is missing or damaged, contact Siemens for assistance.
Section 2.3
Mounting the Device
The RUGGEDCOM RSL910 is designed for maximum mounting and display flexibility. It can be equipped with
adapters that allow it to be installed on a 35 mm (1.4 in) DIN rail or affixed to a panel.
IMPORTANT!
Heat generated by the device is channeled outwards from the enclosure. As such, it is recommended
that 2.5 cm (1 in) of space be maintained on all open sides of the device to allow for some
convectional airflow.
Forced airflow is not required. However, any increase in airflow will result in a reduction of ambient
temperature and improve the long-term reliability of all equipment mounted in the rack space.
8
RUGGEDCOM RSL910
Installation Guide
Unpacking the Device
