Heritage Bathrooms Granley Fitting Instructions

Deck mounted bath shower mixer

Granley

Deck Mounted Bath Shower Mixer

Fitting Instructions

Please keep these instructions for future reference and request of replacement parts

Before starting any installation project please consider the following:

Prior to drilling into walls, check there are no hidden electrical wires

or cables or water supply pipes with the aid of an electrical detector.

If you use power tools do not forget:

- Wear eye protection

- Unplug equipment after use

Table of Contents

Need help?

Do you have a question about the Granley and is the answer not in the manual?

Page 1 Granley Deck Mounted Bath Shower Mixer Fitting Instructions Before starting any installation project please consider the following: Prior to drilling into walls, check there are no hidden electrical wires or cables or water supply pipes with the aid of an electrical detector.
Page 2 Water Pressure. This mixer is suitable for minimum of 0.2bar, however for optimum performance both the hot & cold supplies should be reasonable balanced. This mixer should be installed in compliance with Water Regulations. Where supplies are unbalanced i.e. hot water from the cylinder tank/cold from the mains, then approved check valves must be fitted in the supply pipes.
Page 3 Maintenance. If the fitting begins to drip 1. Isolate water supplies, unscrew indice from the head, remove head screw & lift off the head. 2. Unscrew the valve shroud & valve, carefully clean tap & seating rubber washer on the valve. 3.
Page 4 If you require further assistance please contact Heritage Sales and Technical Enquiries: Sales : 0844 701 8501 Technical: 0844 701 8503 Email: Technical@heritagebathrooms.com Website: www.heritagebathrooms.com Heritage Bathrooms Unit 6 Albert Road St Philips Central Bristol BS2 0XJ (HFI TGRC/TGRG02) (REV D1)
